Automatic day/night mirror circuit for Chrysler Town & Country V facelift (2010-2016)
Automatic day/night mirror circuit
BACKUP LAMP FD
BACKUP LAMP RELAY
BLK WIRE
BLK/RED WIRE
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DK GRN/LT BLU WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
DRIVER DOOR MODULE (DRIVER FRONT DOOR)
EC MIRR RTN
EC MRR RTN
HANDS FREE MODULE
HOT W/ RUN/ START RELAY ENERGIZED
IGN RS
INSIDE REARVIEW MIRROR
LT BLU/DK GRN WIRE
LT BLU/WHT WIRE
LT GRN/DK BLU WIRE
MICROPHONE 1 IN (+)
MICROPHONE 2 IN (+)
MICROPHONE FEED
MICROPHONE IN (-)
ORG/GRY WIRE
OUT SIDE EC MIRR SIG
OUTSIDE EC MRR SIG
PNK/LT GRN WIRE
SNSR GND
TAN/ORG WIRE
TAN/WHT WIRE
TOTALLY INTEGRATED POWER MODULE
VIO/BLK WIRE
W/ RAIN SENSOR
W/O RAIN SENSOR
WHT/GRY WIRE
WHT/LT GRN WIRE
WHT/ORG WIRE
