Computer data lines circuit for Chrysler Town & Country V facelift (2010-2016)

A/C HEATER CONTROL ANTI-LOCK BRAKES MODULE (LEFT FRONT OF ENGINE COMPT) B(+) BLK/RED WIRE CAN BUS (-) YAW CAN C (+) CAN IHS (-) CAN IHS CAN IHS CAN-BUS CIRCUIT BOARD CLUSTER D DIAG (+) DATA LINK CONNECTOR (BELOW LEFT SIDE OF DASH) DRIVER WINDOW/ DOOR LOCK SWITCH DYNAMICS SENSOR (UNDER CENTER CONSOLE) EXCEPT LIMITED HANDS FREE MODULE (BEHIND LEFT END OF DASH) HOT AT ALL TIMES INSIDE REARVIEW MIRROR (IF EQUIPPED) LIMITED LIN BUS LIN CCN LIN DCM DR LIN TIRE PRESS LT GRN/LT BLU WIRE MONITOR/DVD MEDIA SYSTEM (IF EQUIPPED) OCCUPANT RESTRAINT CONTROLLER MODULE (UNDER CENTER OF DASH) PASSIVE ENTRY MODULE (IF EQUIPPED) (RIGHT SIDE OF DASH) POWERTRAIN CONTROL MODULE (BOTTOM LEFT OF TRANSMISSION) RADIO RAIN SENSOR (IF EQUIPPED) (TOP CENTER WINDSHIELD) RED WIRE TIRE PRESSURE MODULE (IF EQUIPPED) (BOTTOM OF LEFT "C" PILLAR) TOTALLY INTEGRATED POWER MODULE VIDEO SCREEN 1 MODULE (IF EQUIPPED) WHT WIRE WHT/BRN WIRE WHT/DK BLU WIRE WHT/DK GRN WIRE WHT/GRY WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/ORG WIRE WHT/YEL WIRE WIRELESS IGNITION NODE

BLK WIRE CAN C (+) CAN IHS (-) COMPASS MODULE (TOP CENTER OF DASH) HEATED SEATS MODULE (UNDER DRIVER'S SEAT) INLINE BODY IP RT LEFT POWER SLIDING DOOR MODULE LEFT REAR BLIND-SPOT SENSOR LEFT REAR DOOR MODULE (LEFT REAR DOORS) LIN BUS MEMORY SEAT MODULE (IF EQUIPPED) (UNDER DRIVER'S SEAT) PARK ASSIST MODULE (BEHIND RIGHT QUARTERPANEL) PASSENGER DOOR MODULE (PASSENGER FRONT MODULE) POWER LIFTGATE MODULE (MOUNTED ON LEFT "D" PILLAR) RADIO AMPLIFIER (BEHIND LEFT QUARTERPANEL) RIGHT POWER SLIDING DOOR MODULE RIGHT REAR BLIND-SPOT SENSOR RIGHT REAR DOOR MODULE (RIGHT REAR DOORS) SPEED CONTROL SWITCH STEERING CONTROL MODULE WHT/BRN WIRE WHT/DK GRN WIRE WHT/GRY WIRE WHT/LT BLU WIRE WHT/ORG WIRE
