Chrysler Town & Country V facelift (2010-2016) rt rr ulk right pwr sliding lck status sig psd dr mux rtn Wiring diagram

AJAR SW SEN AJAR SW SIG B(+) BATT FEED BLK WIRE BLK/ORG WIRE BLK/WHT WIRE CAN B CAN C (+) CAN IHS (-) CIRCUIT BOARD CLUSTER COM SNSR RTN COMPUTER DATA LINES SYSTEM DR AJAR LT SIG DR AJAR SW SENS DR OP/CLS FSD B(+) GROUND HNDLE SIG HOT AT ALL TIMES IGNITION WIRELESS NODE ILL SW LEFT "B" PILLAR SWITCH LEFT CINCH/RELEASE LATCH LEFT CINCH/RELEASE UNLATCH LEFT DR IN/OUT HANDLE SIG LEFT POWER SLIDING DOOR MODULE LEFT REAR DOOR LATCH (LEFT REAR DOOR) LEFT REAR DOOR MODULE (LEFT REAR DOORS) LEFT REAR POWER WINDOW SWITCH LH PWR SLIDING DR MUX RTN LH SLIDING DR LK STOP SIG LR DR LCK LR DR UNLCK LR LCK LT BLU/RED WIRE LT GRN/TAN WIRE LT PSD LK STAT SIG LT PSD LR SEAT SIG MUX RTN OPN SIG ORG/BRN WIRE ORG/DK GRN WIRE ORG/GRY WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE ORG/VIO WIRE ORG/YEL WIRE OVERHEAD CONSOLE PAWL OPEN SIG POWER WINDOWS SYSTEM PSD LOCKOUT SNSC PSD MUX RTN RED WIRE RED/ORG WIRE RH SLIDING DR RIGHT "B" PILLAR SWITCH RIGHT CINCH/RELEASE LATCH RIGHT CINCH/RELEASE UNLATCH RIGHT DR IN/OUT HANDLE SIG RIGHT POWER SLIDING DOOR MODULE RIGHT REAR DOOR LATCH (RIGHT REAR DOOR) RIGHT REAR DOOR MODULE (RIGHT REAR DOORS) RIGHT REAR POWER WINDOW SWITCH RR DSD LP PAWL OPN SIG DR MUX RTN RR LT PSD MUX RR LT PSD MUX RTN RR RT PSD MUX RTN RR SIG RT RR DR LCK RT RR DR UNLCK RT RR ULK RIGHT PWR SLIDING LCK STATUS SIG PSD DR MUX RTN RT RR UNLCK RT RR UNLCK LK SECTOR GEAR SW LT SECTOR GEAR SW RT SIG LT SIG RT SW ILLUMINATION DRV SW ILLUMINATION LT SW RTN TAN/DK BLU WIRE TAN/GRY WIRE TAN/LT BLU WIRE TAN/ORG WIRE TAN/VIO WIRE TAN/WHT WIRE TOTALLY INTEGRATED POWER MODULE VIO/DK BLU WIRE VIO/DK GRN WIRE VIO/GRY WIRE VIO/YEL WIRE WHT WIRE WHT/BRN WIRE WHT/GRY WIRE WHT/LT BLU WIRE WHT/ORG WIRE WHT/RED WIRE
