Chrysler Town & Country V facelift (2010-2016) lt blnd spt ind sig lt blnd spt ind rtn Wiring diagram
This page shows the only wiring diagram for the component.lt blnd spt ind sig lt blnd spt ind rtn, which is found in the car Chrysler Town & Country V facelift (2010-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lt blnd spt ind sig lt blnd spt ind rtn (1 of 1)
BLK/WHT WIRE
BRN WIRE
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DRIVER DOOR MODULE (DRIVER FRONT DOOR)
HOT W/ RUN RELAY ENERGIZED
IGNR
LEFT APPROACH BUND SPOT LAMP, ELECTROCHROMIC OUT SIDE MIRROR
LEFT BLIND SPOT SENSOR
LT BLND SPT IND RTN
LT BLND SPT IND SIG
LT BLND SPT IND SIG LT BLND SPT IND RTN
LT BLU WIRE
PASSENGER DOOR MODULE (PASSENGER FRONT DOOR)
PNK/YEL WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT BLIND SPOT DETECTION LAMP
RIGHT REAR BLIND-SPOT SENSOR
RT BLND SPT IND RTN RT BLND SPT IND SIG
RT BLND SPT IND SIG RT BLND SPT IND RTN
TOTALLY INTEGRATED POWER MODULE
WHT/GRY WIRE
WHT/ORG WIRE
Go to component -> Blind spot monitoring circuit -> LT BLND SPT IND SIG LT BLND SPT IND RTN
