Electronic power steering circuit, autonomous for Chrysler Pacifica RU facelift (2020-2024)
Electronic power steering circuit, autonomous
ARRAY FUSE 1
BLK WIRE
BRN/WHT WIRE
CAN C (+)
CLUSTER
COMPUTER DATA LINES SYSTEM
EPS MODULE (ON STEERING GEAR)
EYELET-2
FUSE 56
FUSED B (+)
HOT AT ALL TIMES
HOT W/ RUN/ START RELAY ENERGIZED
IGNITION RUN-START CTRL OUT
PNK/GRN WIRE
PNK/WHT WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RUN/START RELAY OUTPUT
UPFITTER ACCESS
WHT/DK GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BRN WIRE
