Chrysler Pacifica RU facelift (2020-2024) whl feed Wiring diagram
This page shows the only wiring diagram for the component.whl feed, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram whl feed (1 of 1)
BASE
BLK WIRE
CAN C (+)
CAN IHS (-)
COMFORT SEAT WHEEL MODULE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/GRN WIRE
DK BLU/WHT WIRE
FUSE 91
FUSED IGN
GRY WIRE
GRY/DK BLU WIRE
HEATED STEERING WHEEL
HEATED STR
HEATED STR WHL FEED
HEATED STR WHL FEED HEATED STR WHL RTN
HEATED STR WHL RTN
HEATED STR WHL RTN HEATED STR WHL FEED
HORNS SYSTEM
HOT W/ RUN RELAY 1 ENERGIZED
LEFT STEERING WHEEL SWITCH
LIN BUS
PNK WIRE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWER DISTRIBUTION SYSTEM
PREMIUM
STEERING COLUMN CONTROL MODULE
VIO WIRE
WHL FEED
WHL RTN
WHL SIG
WHT WIRE
WHT/DK BLU WIRE
YEL WIRE
Go to component -> Heated steering wheel circuit -> WHL FEED
