Chrysler Pacifica RU facelift (2020-2024) video screen Wiring diagrams
This page contains all the electrical diagrams for the component. video screen, in which he is found in the car Chrysler Pacifica RU facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram video screen (1 of 2)
AUDIO LH 2
AUDIO RH 1
AUDIO RH 2
AUDIO RTN 1
AUDIO RTN 2
BLK WIRE
CABLE (BU)
CABLE (VT)
CAN IHS (+) AT GROUND
CAN IHS (-)
CAN IHS (-) AT
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN WIRE
DK GRN/BLU WIRE
DK GRN/DK BLU WIRE
DK GRN/TAN WIRE
DK GRN/WHT WIRE
DRV PANEL LAMPS
EXCEPT PHEV
EXTERNAL DISC MODULE (LOWER CENTER OF DASH)
FRONT AUXILIARY VIDEO PORT
FUSE 14
FUSE 25
FUSE 28
FUSE 30
FUSE 55
FUSE 76
FUSED B (+)
FUSED B (+) AUDIO LH 1
GRN WIRE
GROUND
GRY/ORG WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
ORG/GRY WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
PVT CAN (+)
RADIO
RED WIRE
SCREEN CENTER STACK DISPLAY
VIDEO ROUTING MODULE (UNDER FRONT PASSENGER'S SEAT)
VIDEO SCN (LVDS) (BR)
VIDEO SCN (LVDS) (WT)
VIDEO SCN CABLE (BU)
VIDEO SCN CABLE (VT)
VIDEO SCREEN
VIDEO SIG 1
WHT WIRE
WHT/GRY WIRE
WHT/ORG WIRE
Go to component -> Rear seat entertainment circuit (1 of 2) -> VIDEO SCREEN
Wiring diagram video screen (2 of 2)
AUDIO LH 1
AUDIO LH 2
AUDIO RH 1
AUDIO RH 2
AUDIO RTN 1
AUDIO RTN 2
BASE
BLK WIRE
DK GRN/BLU WIRE
DK GRN/DK BLU WIRE
DK GRN/TAN WIRE
DK GRN/WHT WIRE
FUSE 77
FUSED B (+)
GRY/ORG WIRE
GRY/VIO WIRE
HOT W/ RUN/ACCESSORY 1 RELAY ENERGIZED
IGN SW OUTPUT
LEFT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
LEFT SEAT BACK VIDEO SCREEN MODULE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWER DISTRIBUTION SYSTEM
PREMIUM
RED WIRE
RIGHT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
RIGHT SEAT BACK VIDEO SCREEN MODULE
VIDEO SCREEN
Go to component -> Rear seat entertainment circuit (2 of 2) -> VIDEO SCREEN
