Chrysler Pacifica RU facelift (2020-2024) sunroof vent sw sense Wiring diagram
This page shows the only wiring diagram for the component.sunroof vent sw sense, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sunroof vent sw sense (1 of 1)
BLK WIRE
ELECTRONIC OVERHEAD MODULE (RIGHT CENTER OF THE HEADLINER)
FSD B(+)
FSD IGN SW OUTPUT (RUN-ACC)
FUSE 35
FUSE 77
HOT AT ALL TIMES
HOT W/ RUN/ ACCESSORY 1 RELAY ENERGIZED
ORG/BLU WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/TAN WIRE
ORG/VIO WIRE
ORG/YEL WIRE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
PWR CLS (+)
PWR OPN (+)
SUNROOF
SUNROOF CLS
SUNROOF CLS SW SENSE
SUNROOF DIAGNOSTIC
SUNROOF MOTOR (FRONT OF ROOF)
SUNROOF OPN
SUNROOF OPN SW SENSE
SUNROOF SHADE
SUNROOF SHADE MOTOR
SUNROOF SHADE PWR CLS (+)
SUNROOF SHADE PWR OPN (+)
SUNROOF SW SPLY
SUNROOF VENT (+)
SUNROOF VENT SW SENSE
SW SENSE
SW SPLY
VIO/RED WIRE
WHT WIRE
Go to component -> Power top/sunroof circuit -> SUNROOF VENT SW SENSE
