Chrysler Pacifica RU facelift (2020-2024) status ind 2 Wiring diagram
This page shows the only wiring diagram for the component.status ind 2, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram status ind 2 (1 of 1)
AUXILIARY PUMP SPLY
BATTERY PACK CONTROL MODULE (UNDER CENTER OF VEHICLE)
BLK WIRE
BPCM LIN BUS
BRN/WHT WIRE
CAN C (+)
CAN C (-) EPT
CHARGE INDICATOR ASSEMBLY
CHARGE TEMP
CHARGE TEMP IND RTN
CLUSTER
COMPUTER
COMPUTER DATA LINES SYSTEM
DK GRN/PNK WIRE
FROM HV BATTERY
FUSED B (+)
GRN/BRN WIRE
HIGH TEMP
HIGH VOLTAGE
HIGH VOLTAGE FUSE B
HIGH VOLTAGE FUSE C
HIGH VOLTAGE INTERLOCK SAFETY LOOP 1
HIGH VOLTAGE INTERLOCK SAFETY LOOP 2
HV BATT CHARGE
HV BATT CHARGE STATUS IND 1
HV BATT CHARGE STATUS IND 2
HV BATT CHARGE STATUS IND 3
HV BATT CHARGE STATUS IND 4
HV BATT CHARGE STATUS IND 5
IND RTN
MANUAL SERVICE DISCONNECT
MASTER WAKE-UP SIG
N/A
OCCTOS SIG
ORG/ WIRE
ORG/BLK WIRE
PIM LIN BUD 1 (A)
PIM WAKE-UP SIG
PNK/GRN WIRE
RED WIRE
RED/VIO WIRE
STATUS IND 1
STATUS IND 2
STATUS IND 3
STATUS IND 4
STATUS IND 5
SYSTEM DATA LINES
VIO WIRE
VIO/GRN WIRE
VIO/ORG WIRE
VIO/TAN WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/BLU WIRE
WHT/DK BLU WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
YEL/DK BLU WIRE
YEL/GRY WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Wiring diagram engine performance 3.6l hybrid, hybrid system circuit (3 of 7) -> STATUS IND 2
