Chrysler Pacifica RU facelift (2020-2024) starter solenoid relay Wiring diagrams
This page contains all the electrical diagrams for the component. starter solenoid relay, in which he is found in the car Chrysler Pacifica RU facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram starter solenoid relay (1 of 5)
AC POWER OUTLET
AUTO SHUT DOWN RELAY
BASE
BLK WIRE
BODY CONTROL MODULE
BRN/ORG WIRE
COMFORT SEAT WHEEL MODULE
FROM FUSE 95 (DIAGRAM 1 OF 8)
FROM RUN/ ACCESSORY 1 RELAY (DIAGRAM 1 OF 8)
FROM RUN/START RELAY (DIAGRAM 3 OF 8)
FROM STOP/ START RELAY (DIAGRAM 6 OF 8)
FRONT BLOWER MOTOR RELAY
FSD B(+)
FUEL PUMP RELAY
FUSE 17
FUSE 24
FUSE 40
FUSE 45
FUSE 51
FUSE 88
FUSE 89
FUSE 91
FUSE 96
GRN WIRE
GRN/BLU WIRE
GRN/DK BLU WIRE
GRN/ORG WIRE
HEADLAMP WASHER RELAY
HORN RELAY
INVERTER
INVERTER SW SIG
LEFT HID HEADLAMPS RELAY
LEFT SEAT BACK VENT MOTOR
LEFT SEAT CUSHION VENT MOTOR
LEFT TRAILER TOW RELAY
OCCUPANT RESTRAINT CONTROLLER MODULE
PNK/VIO WIRE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
PREMIUM
REAR BLOWER MOTOR RELAY
REAR WINDOW DEFOGGER RELAY
REAR WIPER RELAY
RED/GRN WIRE
RIGHT HID HEADLAMPS RELAY
RIGHT SEAT BACK VENT MOTOR
RIGHT SEAT CUSHION VENT MOTOR
RIGHT TRAILER TOW RELAY
RUN 1 RELAY
RUN 2 RELAY
STARTER SOLENOID RELAY
SW SIG
TO FUSE 100 (DIAGRAM 3 OF 8)
TO FUSE 31 (DIAGRAM 3 OF 8)
TO STOP/START RELAY (DIAGRAM 6 OF 8)
TRAILER TOW BACKUP LAMP RELAY
TRAILER TOW PARK LAMP RELAY
TRANSMISSION OIL PUMP RELAY
VACUUM CLEANER RELAY
W/ HID
W/ STOP/START SYSTEM
W/O STOP/START SYSTEM
WIPER ON/OFF RELAY
Go to component -> Power distribution circuit (2 of 8) -> STARTER SOLENOID RELAY
Wiring diagram starter solenoid relay (2 of 5)
ADAPTIVE CRUISE CONTROL MODULE
ANTI-LOCK BRAKES MODULE
BASE
BODY CONTROL MODULE
CLUSTER
DRIVER MEMORY SEAT MODULE
DRIVER SEAT SWITCH
DRIVETRAIN CONTROL MODULE
DRVR POWER SEAT CIRCUIT BREAKER 1
EXCEPT HYBRID
FORWARD FACING CAMERA
FROM PCR CONTROL RELAY (DIAGRAM 6 OF 8)
FROM POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 3 OF 8)
FROM RUN/START RELAY (DIAGRAM 3 OF 8)
FUSE 14
FUSE 15
FUSE 18
FUSE 30
FUSE 37
FUSE 44
FUSE 54
FUSE 58
FUSE 66
FUSE 67
FUSE 94
FUSE 97
HVAC MODULE
OCCUPANT CLASSIFICATION MODULE
OCCUPANT RESTRAINT CONTROLLER MODULE
PARK ASSIST MODULE
PASS POWER SEAT CIRCUIT BREAKER 2
PASSENGER MEMORY SEAT MODULE
PNK/GRN WIRE
PNK/ORG WIRE
PNK/VIO WIRE
POWER INVERTER MODULE
POWER TRANSFER UNIT
POWERTRAIN CONTROL MODULE
PREMIUM
REAR HVAC MODULE
RED WIRE
RED/DK GRN WIRE
RED/GRY WIRE
SECURITY GATEWAY MODULE
STARTER SOLENOID RELAY
TAN/RED WIRE
TO FUSE 76 (DIAGRAM 5 OF 8)
VIO/RED WIRE
W/ MEMORY
W/ REAR HVAC
W/ STOP/START SYSTEM
W/O MEMORY
W/O STOP/START SYSTEM
Go to component -> Power distribution circuit (4 of 8) -> STARTER SOLENOID RELAY
Wiring diagram starter solenoid relay (3 of 5)
BASE
BLK WIRE
BLU/TAN WIRE
BODY CONTROL MODULE
DK GRN/TAN WIRE
DK GRN/YEL WIRE
FROM FUSE 17 (DIAGRAM 2 OF 8)
FROM POWER CONTROL RELAY (DIAGRAM 1 OF 8)
FROM POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 1 OF 8)
IGN
LEFT "B" PILLAR SWITCH
LEFT BODY HARNESS
LEFT CHARGING USB PORT
LEFT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
LEFT POWER FOLDING SEAT RECLINER SWITCH
LEFT SEAT BACK VIDEO SCREEN MODULE
PCR CONTROL RELAY
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE
PREMIUM
REAR CHARGING USB PORT
RIGHT "B" PILLAR SWITCH
RIGHT BODY HARNESS
RIGHT CHARGING USB PORT
RIGHT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
RIGHT POWER FOLDING SEAT RECLINER SWITCH
RIGHT SEAT BACK VIDEO SCREEN MODULE
STARTER SOLENOID RELAY
STOP/ START RELAY
SW OUT
TO FUSE 14 (DIAGRAM 4 OF 8)
TO RUN 1 RELAY (DIAGRAM 2 OF 8)
VACUUM SWITCH
W/ VIDEO ENTERTAINMENT SYSTEM
W/O POWER SLIDING DOORS
W/O VIDEO ENTERTAINMENT SYSTEM
Go to component -> Power distribution circuit (6 of 8) -> STARTER SOLENOID RELAY
Wiring diagram starter solenoid relay (4 of 5)
B(+)
BASE
BATTERY
BATTERY FUSE TERMINAL
BLK WIRE
BLU/TAN WIRE
BODY CONTROL MODULE
BRN WIRE
CAN C (+)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN/ORG WIRE
DK GRN/YEL WIRE
FSD IGN SW OUT (RUN-START)
FUSE 1
FUSE 13
FUSE 17
FUSE 18
FUSE 30
FUSE 5
FUSE 55
FUSED B (+)
GENERATOR
HOLD-IN
IGN CRANK SENS
IGN RUN/START CTRL OUT
IGN SW POS SIG
INTELLIGENT BATTERY SENSOR
KEYLESS IGNITION NODE MODULE
PNK/VIO WIRE
PNK/WHT WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWERTRAIN CONTROL MODULE
PREMIUM
PULL- IN
RADIO FREQ HUB MODULE
RED WIRE
RUN/START RELAY
RUN/START RLY CTRL
SECURITY K LINE COMM
STARTER
STARTER RLY CTRL
STARTER SOLENOID RELAY
TAN/WHT WIRE
TRANSMISSION CONTROL MODULE
TRS PARK SIG
VIO/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/DK BLU WIRE
YEL/GRY WIRE
Go to component -> Starting circuit, w/o start-stop system -> STARTER SOLENOID RELAY
Wiring diagram starter solenoid relay (5 of 5)
