Chrysler Pacifica RU facelift (2020-2024) run/start relay output Wiring diagram
This page shows the only wiring diagram for the component.run/start relay output, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram run/start relay output (1 of 1)
ARRAY FUSE 1
BLK WIRE
BRN/WHT WIRE
CAN C (+)
CLUSTER
COMPUTER DATA LINES SYSTEM
EPS MODULE (ON STEERING GEAR)
EYELET-2
FUSE 56
FUSED B (+)
HOT AT ALL TIMES
HOT W/ RUN/ START RELAY ENERGIZED
IGNITION RUN-START CTRL OUT
PNK/GRN WIRE
PNK/WHT WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RUN/START RELAY OUTPUT
UPFITTER ACCESS
WHT/DK GRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BRN WIRE
Go to component -> Electronic power steering circuit, autonomous -> RUN/START RELAY OUTPUT
