Chrysler Pacifica RU facelift (2020-2024) right epb actuator a ctrl wiring diagram
This page shows the only wiring diagram for the component.right epb actuator a ctrl, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right epb actuator a ctrl wiring diagram (1 of 1)
ACTUATOR A
ACTUATOR B
ANTI-LOCK BRAKES MODULE (RIGHT SIDE OF ENGINE COMPT)
BLK WIRE
CAN C (+)
COMPUTER DATA LINES SYSTEM
CONTROL
CTRL
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/BLU WIRE
DK GRN/BRN WIRE
DK GRN/GRN WIRE
DK GRN/GRY WIRE
DK GRN/ORG WIRE
DK GRN/TAN WIRE
EPB INDICATOR SIG
EPB SW POSITION SIG 1
EPB SW POSITION SIG 2
EPB SW POSITION SIG 3
EPB SW POSITION SIG 4
FUSE 79
FUSE 94
FUSED B (+)
FUSED B (+) EPB SW POSITION SIG 4
HOT AT ALL TIMES
LEFT EPB
LEFT EPB ACTUATOR A CTRL
LEFT EPB ACTUATOR B CTRL
LEFT REAR ELECTRIC PARKING BRAKE ACTUATOR
ORG/GRY WIRE
PANEL LAMPS DRIVER
PARKING BRAKE SWITCH
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RIGHT EPB
RIGHT EPB ACTUATOR A CTRL
RIGHT EPB ACTUATOR B CTRL
RIGHT REAR ELECTRIC PARKING BRAKE ACTUATOR
TAN/RED WIRE
VIO WIRE
YEL WIRE
Go to component -> Park brake release circuit -> RIGHT EPB ACTUATOR A CTRL
