Chrysler Pacifica RU facelift (2020-2024) rf turn lp drv Wiring diagram
This page shows the only wiring diagram for the component.rf turn lp drv, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf turn lp drv (1 of 1)
7-WAY TRAILER TOW WIRING
BLK WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
BRK LP SW OUT
BRK SIG 1
BRN WIRE
CAN C (+)
CHMSL LAMP
COMPUTER DATA LINES SYSTEM
DK GRN/WHT WIRE
FSD B(+)
FUSE 37
FUSE 79
FUSE 83
GRN WIRE
GROUND
HAZ SW SENSE
HDLP SW MUX
HDLP SW MUX RTN
HDLP/FOG LP SW SIG
HOT AT ALL TIMES
LF PARK LP DRV
LF TURN LP DRV
LH RR LIGHTING FAULT SENSE
LH SIDE MARKER CTRL
LH STOP/TURN FEED
LICENSE PLATE LP DRV
LR PARK LP DRV
ORG/BRN WIRE
ORG/YEL WIRE
PANEL LP DIMMER SW MUX
PANEL LPS DRV
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
RF PARK LP DRV
RF TURN LP DRV
RH RR LIGHTING FAULT SENSE
RH SIDE MARKER CTRL
RH STOP/TURN FEED
RR PARK LP DRV
TAN/ORG WIRE
TRAILER TOW PARK LAMP RELAY
TRAILER TOW TAIL LP RELAY CTRL
VIO/RED WIRE
WHT/BRN WIRE
WHT/DK BLU WIRE
WHT/DK GRN WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/ORG WIRE
WHT/TAN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, premium (1 of 3) -> RF TURN LP DRV
