Chrysler Pacifica RU facelift (2020-2024) rf seat vent ctrl Wiring diagram
This page shows the only wiring diagram for the component.rf seat vent ctrl, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rf seat vent ctrl (1 of 1)
BASE
BLK WIRE
BRN/GRN WIRE
CAN IHS (-)
COMFORT SEAT WHEEL MODULE (UNDER PASSENGER'S SEAT)
COMPUTER DATA LINES SYSTEM
DK BLU/GRN WIRE
FUSE 34
FUSE 50
FUSE 88
FUSE 89
FUSE 91
FUSED IGN
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRY/DK BLU WIRE
HEATED SEAT SENS RTN
HEATED STEERING WHEEL CIRCUIT
HEATED STR WHL FEED
HEATED STR WHL RTN
HOT AT ALL TIMES
HOT W/ RUN 1 RELAY ENERGIZED
HOT W/ RUN 2 RELAY ENERGIZED
LEFT SEAT BACK VENT MOTOR
LEFT SEAT CUSHION VENT MOTOR
LF HEATED SEAT TEMP SNS
LF SEAT
LF SEAT HEATER CTRL
LF SEAT VENT CTRL
LR HEATED SEAT TEMP SNS
LR SEAT HEATER CTRL
ORG/GRN WIRE
PNK WIRE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
PREMIUM
RED WIRE
RF HEATED SEAT TEMP SNS
RF SEAT
RF SEAT HEATER CTRL
RF SEAT VENT CTRL
RIGHT SEAT BACK VENT MOTOR
RIGHT SEAT CUSHION VENT MOTOR
RR HEATED SEAT TEMP SNS
RR SEAT HEATER CTRL
TAN/DK BLU WIRE
TAN/ORG WIRE
TAN/WHT WIRE
TAN/YEL WIRE
VENT CTRL
WHT WIRE
WHT/DK BLU WIRE
YEL WIRE
Go to component -> Heated seats circuit, w/ ventilation (1 of 2) -> RF SEAT VENT CTRL
