Chrysler Pacifica RU facelift (2020-2024) rf passive entry handle sw rtn Wiring diagram

ANT 1 RTN ANT 1 SIG ANT 2 RTN ANT 2 SIG ANT 4 RTN ANT 4 SIG ANT 5 RTN ANT 5 SIG ANT UHF ANT SIG BASE BLK WIRE BODY CONTROL MODULE (LEFT END OF DASH) CAN C (+) COMPUTER DATA LINES SYSTEM DK BLU WIRE EXTERIOR SW RTN FUSE 55 FUSED B (+) FUSED B (+) IGN SW POSITION SIG GRN/ORG WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/DK GRN WIRE GRY/GRN WIRE GRY/ORG WIRE GRY/TAN WIRE GRY/VIO WIRE HANDLE SW RTN HANDLE SW SNS HOT AT ALL TIMES IGN RUN/START CTRL OUTPUT IGN SW POSITION SIG KEYLESS IGNITION NODE MODULE LEFT FRONT EXTERIOR DOOR HANDLE SWITCH LF PASSIVE ENTRY LF PASSIVE ENTRY HANDLE SW RTN LF PASSIVE ENTRY HANDLE SW SNS LIFTGATE LIFTGATE HANDLE LIFTGATE HANDLE EXTERIOR SW RTN LIFTGATE HANDLE SW SNS PASSIVE ENTRY ANT 1 RTN PASSIVE ENTRY ANT 1 SIG PASSIVE ENTRY ANT 2 RTN PASSIVE ENTRY ANT 2 SIG PASSIVE ENTRY ANT 4 RTN PASSIVE ENTRY ANT 4 SIG PASSIVE ENTRY ANT 5 RTN PASSIVE ENTRY ANT 5 SIG PASSIVE ENTRY ANTENNA 1 PASSIVE ENTRY ANTENNA 2 PASSIVE ENTRY ANTENNA 4 PASSIVE ENTRY ANTENNA 5 PNK/WHT WIRE POWER DISTRIBUTION CENTER ASSEMBLY POWER LIFTGATE HANDLE SWITCH PREMIUM RADIO FREQ HUB MODULE (REAR CENTER OF ROOF) RED WIRE REMOTE START ANTENNA RF PASSIVE ENTRY RF PASSIVE ENTRY HANDLE SW RTN RF PASSIVE ENTRY HANDLE SW SNS RIGHT FRONT EXTERIOR DOOR HANDLE SWITCH SECURITY K LINE COMM TAN/BLU WIRE TAN/DK GRN WIRE TRANSMISSION CONTROL MODULE TRS PARK SIG TRS PRK SIG VIO/BLU WIRE W/ FLOOR CONSOLE W/ INTEGRATED CONSOLE WHT/GRN WIRE YEL WIRE YEL/DK BLU WIRE
