Chrysler Pacifica RU facelift (2020-2024) rad fan ctrl sig Wiring diagrams

This page contains all the electrical diagrams for the component. rad fan ctrl sig, in which he is found in the car Chrysler Pacifica RU facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram rad fan ctrl sig (1 of 4)

Wiring diagram rad fan ctrl sig for Chrysler Pacifica RU facelift (2020-2024) (1 of 4)

Get access

3.6L 3.6L HYBRID 5 VOLT SPLY A/C CLUTCH CTRL A/C PRES SIG A/C PRESS SIG A/C PRESSURE TRANSDUCER ARRAY FUSE 5 BATTERY FUSE TERMINAL BLK WIRE BLU/BRN WIRE BLU/ORG WIRE BRN/VIO WIRE BRN/WHT WIRE CAN C (+) COMPUTER DATA LINES SYSTEM DK BLU/DK GRN WIRE ECT SIG ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR FSD B(+) FUSE 4 FUSE 70 HEAVY DUTY HOT AT ALL TIMES LIGHT DUTY POWER DISTRIBUTION CENTER ASSEMBLY POWERTRAIN CONTROL MODULE (3.6L) (LEFT REAR OF ENGINE COMPT) RAD FAN CTRL SIG RADIATOR FAN RED WIRE RED/BRN WIRE SENS GND TAN/WHT WIRE VIO/BRN WIRE VIO/ORG WIRE YEL WIRE

Go to component -> Automatic a/c circuit (5 of 5) -> RAD FAN CTRL SIG

Wiring diagram rad fan ctrl sig (2 of 4)

Wiring diagram rad fan ctrl sig for Chrysler Pacifica RU facelift (2020-2024) (2 of 4)

Get access

3.6L 3.6L HYBRID ARRAY FUSE 5 BATTERY COOLANT LEVEL SENSOR BATTERY FUSE TERMINAL BLK WIRE BRN/VIO WIRE CAN C (+) COMPUTER DATA LINES SYSTEM COOLANT COOLANT SENS SPLY COOLANT TEMP SENS 2 COOLANT TEMP SENS 3 GND COOLANT VLV 2 CTRL DK BLU/DK GRN WIRE DK GRN/GRY WIRE ECT SIG ENGINE CONTROLS SYSTEM ENGINE COOLANT TEMPERATURE SENSOR FAN CTRL SIG FSD IGN SW OUT (RUN-START) FUSE 30 FUSE 4 FUSED B (+) GRY/BLU WIRE GRY/DK BLU WIRE GRY/ORG WIRE GRY/VIO WIRE HEATER CORE COOLANT TEMPERATURE SENSOR HEAVY DUTY HOT AT ALL TIMES HOT W/ RUN/START RELAY ENERGIZED LIGHT DUTY ORG/PNK WIRE ORG/WHT WIRE PASSIVE PUMP COOLANT TEMPERATURE SENSOR PNK/VIO WIRE POWER DISTRIBUTION CENTER ASSEMBLY POWER INVERTER MODULE (3.6L HYBRID) (TOP REAR SIDE OF ENGINE) POWERTRAIN CONTROL MODULE RAD FAN CTRL SIG RADIATOR FAN RED/BRN WIRE REFRIGERANT SHUT-OFF VALVE SENS GND SENS GND 1 SENS GND 2 SHUT OFF VLV CTRL SHUT-OFF HIGH TEMPERATURE VALVE TAN/WHT WIRE TEMP SENS 2 TEMP SENS 3 VIO/ORG WIRE VIO/WHT WIRE VLV CTRL YEL WIRE

Go to component -> Cooling fan circuit -> RAD FAN CTRL SIG

Wiring diagram rad fan ctrl sig (3 of 4)

Wiring diagram rad fan ctrl sig for Chrysler Pacifica RU facelift (2020-2024) (3 of 4)

Get access

5 VOLT SPLY A/C CLUTCH CTRL A/C PRESS SIG A/C PRESSURE TRANSDUCER ANTI-LOCK BRAKES SYSTEM APP SENS GND 1 APP SENS GND 2 APP SIG (1) APP SIG (2) ASD CTRL O/P ASD RLY CTRL BLK WIRE BLU/BRN WIRE BLU/ORG WIRE BRN WIRE BRN/DK BLU WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CHANGEOVER COOLING FANS SYSTEM CTRL DK BLU/GRN WIRE DK BLU/ORG WIRE DK BLU/TAN WIRE DK BLU/WHT WIRE DK GRN/GRY WIRE DK GRN/ORG WIRE DK GRN/PNK WIRE DK GRN/YEL WIRE ELCM ELCM CHANGEOVER ELCM PRESS ELCM PUMP ELCM PUMP CTRL ESM SIG EVAP LEAK CHECK MODULE EVAP PURGE EVAP PURGE CTRL EVAP SYSTEM MONITOR SWITCH EVAP/PURGE SOLENOID EXCEPT PHEV FPCM PWM CTRL FPCM PWM FEEDBACK FUEL DOOR UNLOCK SOLENOID FUEL PUMP CTRL FUEL TANK PRESS SIG FUSED ASD FUSED B (+) GRY/BLU WIRE POWERTRAIN CONTROL MODULE RAD FAN CTRL SIG RED WIRE RLY O/P SENS GND SENS SIG STARTER RLY CTRL STARTING/ CHARGING SYSTEM VACUUM PUMP RLY CTRL VAL CTRL VIO/BLU (OR BLU/ORG) WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/RED WIRE VIO/WHT WIRE WHT/BRN WIRE

Go to component -> Wiring diagram engine performance 3.6l (2 of 7) -> RAD FAN CTRL SIG
