Chrysler Pacifica RU facelift (2020-2024) pedestrian alert speaker Wiring diagram
This page shows the only wiring diagram for the component.pedestrian alert speaker, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pedestrian alert speaker (1 of 1)
BLK WIRE
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/ORG WIRE
DK BLU/VIO WIRE
ELECTRIC VEH SPKR (-)
ELECTRIC VEHICLE SPKR (-)
FUSE 100
FUSED IGN
HOT W/ RUN 1 RELAY ENERGIZED
LIN BUS CBC 1
ORG/ WIRE
PEDESTRIAN ALERT SPEAKER
PEDESTRIAN ALERT SPEAKER MODULE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
VIO WIRE
Go to component -> Pedestrian alert circuit -> PEDESTRIAN ALERT SPEAKER
