Chrysler Pacifica RU facelift (2020-2024) pass wind hall sens rtn Wiring diagram

BLK WIRE BLK/GRN WIRE BLK/GRY WIRE CAN IHS (-) COMPUTER DATA LINES SYSTEM DOOR LOCKS SYSTEM FSD B(+) GROUND ORG/BLU WIRE ORG/BRN WIRE ORG/DK BLU WIRE ORG/GRN WIRE ORG/GRY WIRE ORG/TAN WIRE ORG/VIO WIRE ORG/WHT WIRE PASS DR LK SW MUX PASS RR WIND DRV (DOWN) PASS RR WIND DRV (UP) PASS WIND DRV DOWN PASS WIND DRV DWN PASS WIND DRV UP PASS WIND HALL SENS A SIG PASS WIND HALL SENS RTN PASS WIND HALL SENS SPLY PASS WIND SW ILL DRV PASS WIND SW MUX PASS WIND SW RTN PASSENGER DOOR MODULE (CENTER OF PASSENGER'S DOOR) PASSENGER WINDOW MOTOR PASSENGER WINDOW/ DOOR LOCK SWITCH RED WIRE RH PWR SLIDING DR MUX RTN RIGHT REAR DOOR RIGHT REAR DOOR MODULE (REAR OF RIGHT REAR DOOR) RIGHT REAR POWER WINDOW SWITCH (PREMIUM 1) RIGHT REAR POWER WINDOW SWITCH (PREMIUM 2) RIGHT REAR WINDOW MOTOR (PREMIUM 1) RIGHT REAR WINDOW MOTOR (PREMIUM 2) RR MSTR WIND SW DWN RR MSTR WIND SW UP RR PWR WIND SW LK OUT FED RR WIND HALL SENS A SIG RR WIND HALL SENS SPLY RR WIND SENS RTN RR WIND SW MUX SW ILL DRV TAN/GRN WIRE VIO/GRN WIRE W/ DOOR HANDLE LAMP W/O DOOR HANDLE LAMP WHT WIRE WHT/BRN WIRE WHT/TAN WIRE YEL WIRE YEL/WHT WIRE
