Chrysler Pacifica RU facelift (2020-2024) liftgate handle Wiring diagram
This page shows the only wiring diagram for the component.liftgate handle, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram liftgate handle (1 of 1)
ANT 1 RTN
ANT 1 SIG
ANT 2 RTN
ANT 2 SIG
ANT 4 RTN
ANT 4 SIG
ANT 5 RTN
ANT 5 SIG
ANT UHF ANT SIG
BASE
BLK WIRE
BODY CONTROL MODULE (LEFT END OF DASH)
CAN C (+)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
EXTERIOR SW RTN
FUSE 55
FUSED B (+)
FUSED B (+) IGN SW POSITION SIG
GRN/ORG WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/DK GRN WIRE
GRY/GRN WIRE
GRY/ORG WIRE
GRY/TAN WIRE
GRY/VIO WIRE
HANDLE SW RTN
HANDLE SW SNS
HOT AT ALL TIMES
IGN RUN/START CTRL OUTPUT
IGN SW POSITION SIG
KEYLESS IGNITION NODE MODULE
LEFT FRONT EXTERIOR DOOR HANDLE SWITCH
LF PASSIVE ENTRY
LF PASSIVE ENTRY HANDLE SW RTN
LF PASSIVE ENTRY HANDLE SW SNS
LIFTGATE
LIFTGATE HANDLE
LIFTGATE HANDLE EXTERIOR SW RTN
LIFTGATE HANDLE SW SNS
PASSIVE ENTRY ANT 1 RTN
PASSIVE ENTRY ANT 1 SIG
PASSIVE ENTRY ANT 2 RTN
PASSIVE ENTRY ANT 2 SIG
PASSIVE ENTRY ANT 4 RTN
PASSIVE ENTRY ANT 4 SIG
PASSIVE ENTRY ANT 5 RTN
PASSIVE ENTRY ANT 5 SIG
PASSIVE ENTRY ANTENNA 1
PASSIVE ENTRY ANTENNA 2
PASSIVE ENTRY ANTENNA 4
PASSIVE ENTRY ANTENNA 5
PNK/WHT WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWER LIFTGATE HANDLE SWITCH
PREMIUM
RADIO FREQ HUB MODULE (REAR CENTER OF ROOF)
RED WIRE
REMOTE START ANTENNA
RF PASSIVE ENTRY
RF PASSIVE ENTRY HANDLE SW RTN
RF PASSIVE ENTRY HANDLE SW SNS
RIGHT FRONT EXTERIOR DOOR HANDLE SWITCH
SECURITY K LINE COMM
TAN/BLU WIRE
TAN/DK GRN WIRE
TRANSMISSION CONTROL MODULE
TRS PARK SIG
TRS PRK SIG
VIO/BLU WIRE
W/ FLOOR CONSOLE
W/ INTEGRATED CONSOLE
WHT/GRN WIRE
YEL WIRE
YEL/DK BLU WIRE
Go to component -> Passive entry circuit -> LIFTGATE HANDLE
