Chrysler Pacifica RU facelift (2020-2024) left seat back video screen module Wiring diagrams
This page contains all the electrical diagrams for the component. left seat back video screen module, in which he is found in the car Chrysler Pacifica RU facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left seat back video screen module (1 of 3)
BASE
BLK WIRE
CARGO LAMP
CENTER CONSOLE LAMP
CIGAR LIGHTER 2
CONSOLE CIGAR LIGHTER
DOME LAMP 2
DRIVER DOOR MODULE
DRIVER LUMBAR SEAT ADJUSTER SWITCH
DRIVER MEMORY SEAT MODULE
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SEAT SWITCH
DRIVER WINDOW/ DOOR LOCK SWITCH
DVD JUMPER
ELECTRONIC OVERHEAD MODULE
EXCEPT PHEV
EXCEPT VENTED SEATS
FRONT BLOWER MOTOR POWER MODULE
FRONT CONSOLE CHARGING USB PORT
FRONT CUPHOLDER LAMP
FUEL DOOR SWITCH
GLOVE BOX LAMP)
IN-CAR TEMPERATURE SENSOR
INTERIOR CAMERA MODULE
LEFT "B" PILLAR SWITCH
LEFT CHARGING USB PORT
LEFT COURTESY LAMP
LEFT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
LEFT LOWER COURTESY LAMP
LEFT SEAT BACK HEATER
LEFT SEAT BACK VENT MOTOR
LEFT SEAT BACK VIDEO SCREEN MODULE
LEFT SEAT CUSHION HEATER
LEFT SEAT CUSHION VENT MOTOR
LEFT VANITY LAMP
MEMORY SET SWITCH
PREMIUM
REAR DOME LAMP
RIGHT COURTESY LAMP
RIGHT VANITY LAMP
SECOND ROW CONSOLE LAMP
SUNROOF MOTOR
SUNROOF SHADE MOTOR
USB PORT
VENTED SEATS
VIDEO SCREEN MODULE
W/ FLOOR CONSOLE
W/ INTEGRATED CONSOLE
W/ VIDEO ENTERTAINMENT SYSTEM
W/O VIDEO ENTERTAINMENT SYSTEM
WIRELESS CHARGING MODULE
Go to component -> Ground distribution circuit (4 of 7) -> LEFT SEAT BACK VIDEO SCREEN MODULE
Wiring diagram left seat back video screen module (2 of 3)
BASE
BLK WIRE
BLU/TAN WIRE
BODY CONTROL MODULE
DK GRN/TAN WIRE
DK GRN/YEL WIRE
FROM FUSE 17 (DIAGRAM 2 OF 8)
FROM POWER CONTROL RELAY (DIAGRAM 1 OF 8)
FROM POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 1 OF 8)
IGN
LEFT "B" PILLAR SWITCH
LEFT BODY HARNESS
LEFT CHARGING USB PORT
LEFT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
LEFT POWER FOLDING SEAT RECLINER SWITCH
LEFT SEAT BACK VIDEO SCREEN MODULE
PCR CONTROL RELAY
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE
PREMIUM
REAR CHARGING USB PORT
RIGHT "B" PILLAR SWITCH
RIGHT BODY HARNESS
RIGHT CHARGING USB PORT
RIGHT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
RIGHT POWER FOLDING SEAT RECLINER SWITCH
RIGHT SEAT BACK VIDEO SCREEN MODULE
STARTER SOLENOID RELAY
STOP/ START RELAY
SW OUT
TO FUSE 14 (DIAGRAM 4 OF 8)
TO RUN 1 RELAY (DIAGRAM 2 OF 8)
VACUUM SWITCH
W/ VIDEO ENTERTAINMENT SYSTEM
W/O POWER SLIDING DOORS
W/O VIDEO ENTERTAINMENT SYSTEM
Go to component -> Power distribution circuit (6 of 8) -> LEFT SEAT BACK VIDEO SCREEN MODULE
Wiring diagram left seat back video screen module (3 of 3)
AUDIO LH 1
AUDIO LH 2
AUDIO RH 1
AUDIO RH 2
AUDIO RTN 1
AUDIO RTN 2
BASE
BLK WIRE
DK GRN/BLU WIRE
DK GRN/DK BLU WIRE
DK GRN/TAN WIRE
DK GRN/WHT WIRE
FUSE 77
FUSED B (+)
GRY/ORG WIRE
GRY/VIO WIRE
HOT W/ RUN/ACCESSORY 1 RELAY ENERGIZED
IGN SW OUTPUT
LEFT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
LEFT SEAT BACK VIDEO SCREEN MODULE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWER DISTRIBUTION SYSTEM
PREMIUM
RED WIRE
RIGHT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
RIGHT SEAT BACK VIDEO SCREEN MODULE
VIDEO SCREEN
Go to component -> Rear seat entertainment circuit (2 of 2) -> LEFT SEAT BACK VIDEO SCREEN MODULE
