Chrysler Pacifica RU facelift (2020-2024) lamp drv Wiring diagrams
This page contains all the electrical diagrams for the component. lamp drv, in which he is found in the car Chrysler Pacifica RU facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
lamp drv wiring diagram (1 of 3)
BACKUP LAMPS CIRCUIT
BASE
BLK WIRE
FAULT SENS
FAULT SENSE
GRN WIRE
LAMP DRV
LEFT FRONT SIDE MARKER LAMP
LEFT LIFTGATE TAIL LAMP ASSEMBLY
LEFT REAR SIDE MARKER LAMP
LEFT TAIL LAMP ASSEMBLY
LF STOP/TURN FEED
LH BACKUP LP DRV
LH RR LIGHTING
LH RR PARK
LH SIDE MARKER CTRL
LIFTGATE LIGHT BAR ASSEMBLY
LR PARK LP DRV
PREMIUM
RED WIRE
RH BACKUP LP DRV
RH RR LIGHTING
RH RR PARK
RH SIDE MARKER CTRL
RH STOP/TURN FEED
RIGHT FRONT SIDE MARKER LAMP
RIGHT LIFTGATE TAIL LAMP ASSEMBLY
RIGHT REAR SIDE MARKER LAMP
RIGHT TAIL LAMP ASSEMBLY
RR PARK LP DRV
TAN/ORG WIRE
WHT WIRE
WHT/GRY WIRE
WHT/ORG WIRE
WHT/TAN WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, base (3 of 3) -> LAMP DRV
lamp drv wiring diagram (2 of 3)
BACKUP LAMPS CIRCUIT
BASE
BLK WIRE
BRAKE PEDAL TRAVEL SENSOR
BRK SIG 1
CAN C (+)
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DK GRN/BRN WIRE
DK GRN/ORG WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
EXCEPT HYBRID
FAULT SENSE
FUSED B (+)
GRN WIRE
HAZ SW SENSE
HDLP SW MUX
HDLP SW MUX RTN
HDLP/FOG LP SW SIG
HEADLAMP SWITCH
INTEGRATED CENTER STACK SWITCH BANK MODULE
LAMP DRV
LEFT LICENSE LAMP
LEFT LIFTGATE TAIL LAMP ASSEMBLY
LEFT TAIL LAMP ASSEMBLY
LF STOP/TURN FEED
LH BACKUP LP DRV
LH RR LIGHTING
LH RR PARK
LICENSE PLATE LP DRV
LR PARK LP DRV
ORG/ WIRE
ORG/BRN WIRE
ORG/GRY WIRE
ORG/YEL WIRE
PANEL LPS DIMMER
PANEL LPS DRIV
PANEL LPS DRV
PED TRVL SENS FD
PED TRVL SENS FEED
PED TRVL SENS RTN
PED TRVL SENS SIG
PREMIUM
RED WIRE
RIGHT LICENSE LAMP
SW MUX
TAN/ORG WIRE
TRAILER TOW CIRCUIT
WHT WIRE
WHT/BRN WIRE
WHT/DK BLU (OR BLK) WIRE
WHT/DK BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/ORG WIRE
WHT/TAN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, premium (2 of 3) -> LAMP DRV
lamp drv wiring diagram (3 of 3)
BACKUP LAMPS CIRCUIT
BASE
BLK WIRE
FAULT SENS
GRN WIRE
LAMP DRV
LEFT FRONT SIDE MARKER LAMP
LEFT REAR SIDE MARKER LAMP
LH SIDE MARKER CTRL
LIFTGATE LIGHT BAR ASSEMBLY
PREMIUM
RED WIRE
RH BACKUP LP DRV
RH RR LIGHTING
RH RR PARK
RH SIDE MARKER CTRL
RH STOP/TURN FEED
RIGHT FRONT SIDE MARKER LAMP
RIGHT LIFTGATE TAIL LAMP ASSEMBLY
RIGHT REAR SIDE MARKER LAMP
RIGHT TAIL LAMP ASSEMBLY
RR PARK LP DRV
TAN/ORG WIRE
WHT WIRE
WHT/ORG WIRE
WHT/TAN WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, premium (3 of 3) -> LAMP DRV
