Chrysler Pacifica RU facelift (2020-2024) high volt interlock safety loop 3 Wiring diagram
This page shows the only wiring diagram for the component.high volt interlock safety loop 3, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram high volt interlock safety loop 3 (1 of 1)
BATT CHILLER
BATTERY CHILLER SHUT-OFF VALVE
BLK WIRE
BLK/GRY WIRE
BLU/DK BLU WIRE
CAN C (-) EPT
CHARGING PORT AC LINE 1
CHARGING PORT AC LINE 2
CHARGING PORT CTRL PILOT SIG
CHARGING PORT GND
CHARGING PORT PROXIMITY SIG
COMPUTER DATA
COOLANT
DK BLU/TAN WIRE
DK GRN/GRY WIRE
DK GRN/PNK WIRE
FUSED B (+)
GROUND
GRY/DK BLU WIRE
GRY/ORG WIRE
HIGH TEMPERATURE SHUT-OFF VALVE
HIGH VOLT INTERLOCK SAFETY LOOP 2
HIGH VOLT INTERLOCK SAFETY LOOP 3
LINES SYSTEM
MASTER WAKE-UP SIG
ORG/ WIRE
ORG/BLK WIRE
ORG/GRY WIRE
ORG/WHT WIRE
PARK
PIM WAKE-UP SIG FROM HV BATTERY
PIM WAKE-UP SIG FROM OBCM
PNK/GRN WIRE
PNK/ORG WIRE
RADIO FREQ HUB MODULE
RED WIRE
RED/VIO WIRE
REFRIGERANT SHUT-OFF VALVE
SHUT OFF
SIG
TAN/DK BLU WIRE
TRS
VALVE CTRL
VIO/DK BLU WIRE
VIO/DK GRN WIRE
VIO/ORG WIRE
VIO/YEL WIRE
VLV 2 CTRL
WHT/BLU WIRE
WHT/DK BLU WIRE
YEL/BLK WIRE
YEL/DK BLU WIRE
YEL/GRY WIRE
Go to component -> Wiring diagram engine performance 3.6l hybrid, hybrid system circuit (5 of 7) -> HIGH VOLT INTERLOCK SAFETY LOOP 3
