Chrysler Pacifica RU facelift (2020-2024) hdlp sig Wiring diagram
This page shows the only wiring diagram for the component.hdlp sig, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hdlp sig (1 of 1)
ANTI-LOCK BRAKE MODULE
AUTO
AUTO HDLP SIG
BLK WIRE
CAN C (+)
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DK BLU/WHT WIRE
DK GRN WIRE
DK GRN/BLU WIRE
DK GRN/GRN WIRE
DK GRN/GRY WIRE
EPB IND SIG
EPB SW POS 1 SIG
EPB SW POS 2 SIG
EPB SW POS 3 SIG
EPB SW POS 4 SIG
FUSE 79
FUSED B (+)
HDLP SIG
HOT AT ALL TIMES
HVAC MODULE (RIGHT SIDE OF DASH)
ORG/GRY WIRE
PANEL LAMPS DRV
PARKING BRAKE SWITCH
POWER DISTRIBUTION CENTER ASSEMBLY
RED WIRE
SENS GND
SIG (1)
SIG (2)
SUN SENS
SUN SENS SIG 1
SUN SENS SIG 2
SUN SENSOR (TOP CENTER OF DASH)
VIO WIRE
VIO/BLU WIRE
VIO/DK BLU WIRE
VIO/ORG WIRE
W/ AUTO HEADLAMPS
WHT WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Headlights circuit, base (2 of 2) -> HDLP SIG
