Chrysler Pacifica RU facelift (2020-2024) gateway security module wiring diagram
This page shows the only wiring diagram for the component.gateway security module, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
gateway security module wiring diagram (1 of 1)
ACTIVE NOISE CANCELLATION MODULE
AUXILIARY MEDIA HUB MODULE
BASE
BLK WIRE
CENTRAL VISION PROCESSING MODULE
COMFORT SEAT WHEEL MODULE
DATA LINK CONNECTOR
DVD JUMPER
EMERGENCY ASSISTANCE MODULE
EXCEPT VENTED SEATS
EXTERNAL DISC MODULE
FORWARD FACING CAMERA
FRONT AUXILIARY VIDEO PORT
FRONT CHARGING USB PORT
GATEWAY SECURITY MODULE
HEADLAMP SWITCH
HUMIDITY SENSOR
INSIDE REAR VIEW MIRROR
INTEGRATED CENTER STACK SWITCH BANK MODULE
LIGHT RAIN SENSOR MODULE
MEDIA PORT
MEDIA PORT 3
OCCUPANT CLASSIFICATION MODULE
PARKING BRAKE SWITCH
PASSENGER DOOR MODULE
PASSENGER LUMBAR SEAT ADJUSTER SWITCH
PASSENGER MEMORY SEAT MODULE
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER SEAT SWITCH
PASSENGER WINDOW/ DOOR LOCK SWITCH
PREMIUM
RADIO, AMPLIFIER
REAR ELECTRONIC OVERHEAD MODULE
RFV
RIGHT "B" PILLAR SWITCH
RIGHT CHARGING USB PORT
RIGHT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
RIGHT LOWER COURTESY LAMP
RIGHT SEAT BACK HEATER
RIGHT SEAT BACK VENT MOTOR
RIGHT SEAT BACK VIDEO SCREEN MODULE
RIGHT SEAT CUSHION HEATER
RIGHT SEAT CUSHION VENT MOTOR
SCREEN CENTER STACK DISPLAY
VENTED SEATS
VIDEO ROUTING MODULE
W/ MANUAL
W/ POWER
W/ VIDEO ENTERTAINMENT SYSTEM
W/O VENTILATION
W/O VIDEO ENTERTAINMENT SYSTEM
Go to component -> Ground distribution circuit (3 of 7) -> GATEWAY SECURITY MODULE
