Chrysler Pacifica RU facelift (2020-2024) front console charging usb port Wiring diagram
This page shows the only wiring diagram for the component.front console charging usb port, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front console charging usb port (1 of 1)
BASE
BLK WIRE
CARGO LAMP
CENTER CONSOLE LAMP
CIGAR LIGHTER 2
CONSOLE CIGAR LIGHTER
DOME LAMP 2
DRIVER DOOR MODULE
DRIVER LUMBAR SEAT ADJUSTER SWITCH
DRIVER MEMORY SEAT MODULE
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SEAT SWITCH
DRIVER WINDOW/ DOOR LOCK SWITCH
DVD JUMPER
ELECTRONIC OVERHEAD MODULE
EXCEPT PHEV
EXCEPT VENTED SEATS
FRONT BLOWER MOTOR POWER MODULE
FRONT CONSOLE CHARGING USB PORT
FRONT CUPHOLDER LAMP
FUEL DOOR SWITCH
GLOVE BOX LAMP)
IN-CAR TEMPERATURE SENSOR
INTERIOR CAMERA MODULE
LEFT "B" PILLAR SWITCH
LEFT CHARGING USB PORT
LEFT COURTESY LAMP
LEFT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
LEFT LOWER COURTESY LAMP
LEFT SEAT BACK HEATER
LEFT SEAT BACK VENT MOTOR
LEFT SEAT BACK VIDEO SCREEN MODULE
LEFT SEAT CUSHION HEATER
LEFT SEAT CUSHION VENT MOTOR
LEFT VANITY LAMP
MEMORY SET SWITCH
PREMIUM
REAR DOME LAMP
RIGHT COURTESY LAMP
RIGHT VANITY LAMP
SECOND ROW CONSOLE LAMP
SUNROOF MOTOR
SUNROOF SHADE MOTOR
USB PORT
VENTED SEATS
VIDEO SCREEN MODULE
W/ FLOOR CONSOLE
W/ INTEGRATED CONSOLE
W/ VIDEO ENTERTAINMENT SYSTEM
W/O VIDEO ENTERTAINMENT SYSTEM
WIRELESS CHARGING MODULE
Go to component -> Ground distribution circuit (4 of 7) -> FRONT CONSOLE CHARGING USB PORT
