Chrysler Pacifica RU facelift (2020-2024) except vented seats Wiring diagrams
This page contains all the electrical diagrams for the component. except vented seats, in which he is found in the car Chrysler Pacifica RU facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram except vented seats (1 of 2)
ACTIVE NOISE CANCELLATION MODULE
AUXILIARY MEDIA HUB MODULE
BASE
BLK WIRE
CENTRAL VISION PROCESSING MODULE
COMFORT SEAT WHEEL MODULE
DATA LINK CONNECTOR
DVD JUMPER
EMERGENCY ASSISTANCE MODULE
EXCEPT VENTED SEATS
EXTERNAL DISC MODULE
FORWARD FACING CAMERA
FRONT AUXILIARY VIDEO PORT
FRONT CHARGING USB PORT
GATEWAY SECURITY MODULE
HEADLAMP SWITCH
HUMIDITY SENSOR
INSIDE REAR VIEW MIRROR
INTEGRATED CENTER STACK SWITCH BANK MODULE
LIGHT RAIN SENSOR MODULE
MEDIA PORT
MEDIA PORT 3
OCCUPANT CLASSIFICATION MODULE
PARKING BRAKE SWITCH
PASSENGER DOOR MODULE
PASSENGER LUMBAR SEAT ADJUSTER SWITCH
PASSENGER MEMORY SEAT MODULE
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER SEAT SWITCH
PASSENGER WINDOW/ DOOR LOCK SWITCH
PREMIUM
RADIO, AMPLIFIER
REAR ELECTRONIC OVERHEAD MODULE
RFV
RIGHT "B" PILLAR SWITCH
RIGHT CHARGING USB PORT
RIGHT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
RIGHT LOWER COURTESY LAMP
RIGHT SEAT BACK HEATER
RIGHT SEAT BACK VENT MOTOR
RIGHT SEAT BACK VIDEO SCREEN MODULE
RIGHT SEAT CUSHION HEATER
RIGHT SEAT CUSHION VENT MOTOR
SCREEN CENTER STACK DISPLAY
VENTED SEATS
VIDEO ROUTING MODULE
W/ MANUAL
W/ POWER
W/ VIDEO ENTERTAINMENT SYSTEM
W/O VENTILATION
W/O VIDEO ENTERTAINMENT SYSTEM
Go to component -> Ground distribution circuit (3 of 7) -> EXCEPT VENTED SEATS
Wiring diagram except vented seats (2 of 2)
BASE
BLK WIRE
CARGO LAMP
CENTER CONSOLE LAMP
CIGAR LIGHTER 2
CONSOLE CIGAR LIGHTER
DOME LAMP 2
DRIVER DOOR MODULE
DRIVER LUMBAR SEAT ADJUSTER SWITCH
DRIVER MEMORY SEAT MODULE
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SEAT SWITCH
DRIVER WINDOW/ DOOR LOCK SWITCH
DVD JUMPER
ELECTRONIC OVERHEAD MODULE
EXCEPT PHEV
EXCEPT VENTED SEATS
FRONT BLOWER MOTOR POWER MODULE
FRONT CONSOLE CHARGING USB PORT
FRONT CUPHOLDER LAMP
FUEL DOOR SWITCH
GLOVE BOX LAMP)
IN-CAR TEMPERATURE SENSOR
INTERIOR CAMERA MODULE
LEFT "B" PILLAR SWITCH
LEFT CHARGING USB PORT
LEFT COURTESY LAMP
LEFT FRONT SEAT BACK AUXILIARY AUDIO VIDEO PORT
LEFT LOWER COURTESY LAMP
LEFT SEAT BACK HEATER
LEFT SEAT BACK VENT MOTOR
LEFT SEAT BACK VIDEO SCREEN MODULE
LEFT SEAT CUSHION HEATER
LEFT SEAT CUSHION VENT MOTOR
LEFT VANITY LAMP
MEMORY SET SWITCH
PREMIUM
REAR DOME LAMP
RIGHT COURTESY LAMP
RIGHT VANITY LAMP
SECOND ROW CONSOLE LAMP
SUNROOF MOTOR
SUNROOF SHADE MOTOR
USB PORT
VENTED SEATS
VIDEO SCREEN MODULE
W/ FLOOR CONSOLE
W/ INTEGRATED CONSOLE
W/ VIDEO ENTERTAINMENT SYSTEM
W/O VIDEO ENTERTAINMENT SYSTEM
WIRELESS CHARGING MODULE
Go to component -> Ground distribution circuit (4 of 7) -> EXCEPT VENTED SEATS
