Chrysler Pacifica RU facelift (2020-2024) drv mirr heater rtn Wiring diagram
This page shows the only wiring diagram for the component.drv mirr heater rtn, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv mirr heater rtn (1 of 1)
BASE
BLK WIRE
BRN WIRE
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
CTRL OUTPUT
DEF RLY CTRL
DK BLU WIRE
DK BLU/BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
DRIVER DOOR MODULE
DRIVER OUTSIDE REAR- VIEW MIRROR
DRV MIRR HEATER DRV
DRV MIRR HEATER RTN
ELECTRIC HEATED BACKLITE
FUSE 72
FUSE 73
GROUND
HOT AT ALL TIMES
HVAC MODULE
MIRROR HEATER DRIVER
PASS MIRR HEATER DRV
PASS MIRR HEATER RTN
PASSENGER DOOR MODULE
PASSENGER OUTSIDE REAR VIEW MIRROR
POWER DISTRIBUTION CENTER ASSEMBLY
PREMIUM
REAR WINDOW DEFOGGER RELAY
RR WIND DEF
WHT WIRE
WHT/BRN WIRE
Go to component -> Defoggers circuit -> DRV MIRR HEATER RTN
