Chrysler Pacifica RU facelift (2020-2024) data lines Wiring diagram
This page shows the only wiring diagram for the component.data lines, which is found in the car Chrysler Pacifica RU facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram data lines (1 of 1)
AJAR SW SENSE
BLK WIRE
BRN WIRE
CAN IHS (-)
COMPUTER
COMPUTER DATA LINES SYSTEM
CRTSY LP
CRTSY LP DRV
CRTSY LPS DRV
DATA LINES
DECKLID/LIFTGATE
DRIV DR AMB
DRIVER DOOR HANDLE LAMP
DRIVER DOOR MODULE
DRIVER SIDE POCKET MAP LAMP
DRV DR
DRV DR AMB
FLOOD DOOR COURTESY LAMP
FSD B(+)
GRY WIRE
LEFT COURTESY LAMP
LEFT LOWER COURTESY LAMP
LEFT VANITY LAMP
LIFTGATE LAMP
LIGHTING RTN
LP FD
MEMORY SET SWITCH
ORG/BLU WIRE
ORG/DK BLU WIRE
OVERHEAD ELECTRONIC MODULE
PASS DR AMB LIGHTING FD
PASS DR AMB LP FD
PASS DR AMB LP FD PASS DR LIGHTING RTN
PASS DR CRTSY LP
PASS DR LIGHTING RTN
PASSENGER DOOR HANDLE LAMP
PASSENGER DOOR MODULE
PASSENGER SIDE POCKET MAP LAMP
PNL LAMPS DRV
READING LPS DRV
RED WIRE
RIGHT LOWER COURTESY LAMP
SYSTEM
UGDO ENABLE CTRL
VIO/ORG WIRE
W/ MEMORY
WHT WIRE
WHT/BRN WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Courtesy lamps circuit (4 of 4) -> DATA LINES
