Car Wiring Diagrams for Horn circuit for Chrysler Pacifica RU (2016-2020)

BLK WIRE BODY CONTROL MODULE BRN WIRE CAN C (+) COMPUTER DATA LINES SYSTEM DK BLU/WHT WIRE DK GRN WIRE DK GRN/VIO WIRE DK GRN/WHT WIRE FUSE 71 FUSE 79 FUSED B (+) GND GND GND HORN SW SNS GRY WIRE HEATED STEERING WHEEL HORN FUSED HORN CTRL OUT HORN RELAY HORN RLY CTRL HORN SW SNS HORN SWITCH HOT AT ALL TIMES LEFT REMOTE RADIO SWITCH LEFT STEERING WHEEL SWITCH LT GRN WIRE POWER DISTRIBUTION CENTER ASSEMBLY RED WIRE RIGHT REMOTE RADIO SWITCH SPEED CONTROL SWITCH STEERING COLUMN CONTROL MODULE WHT WIRE YEL WIRE
