Wiring diagram engine performance 3.6l hybrid, virtual engine sound system circuit for Chrysler Pacifica RU (2016-2020)

AHLM BLK WIRE CAN IHS (-) COMPUTER DATA LINES SYSTEM DK BLU/ORG WIRE DK GRN WIRE DK GRN/ORG WIRE ELECTRIC VEH SPEAKER (-) FUSE 100 FUSE 44 FUSED B (+) FUSED IGN HOT AT ALL TIMES HOT W/ RUN RELAY 2 ENERGIZED PEDESTRIAN ALERT PEDESTRIAN ALERT SOUND CTRL PEDESTRIAN ALERT SPEAKER PNK/YEL WIRE POWER DISTRIBUTION CENTER ASSEMBLY POWER DISTRIBUTION SYSTEM RED WIRE SOUND CTRL TAN/DK GRN WIRE VEH SPD SIG VEHICLE PEDESTRIAN ALERT CONTROL UNIT WHT WIRE WHT/GRN WIRE
