Chrysler Pacifica RU (2016-2020) w/ stop/start system w/o stop/start system Wiring diagrams
This page contains all the electrical diagrams for the component. w/ stop/start system w/o stop/start system, in which he is found in the car Chrysler Pacifica RU (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ stop/start system w/o stop/start system (1 of 2)
BASE
BLK WIRE
BODY CONTROL MODULE
BRN/ORG WIRE
FROM RUN/ ACCESSORY RELAY 1 (DIAGRAM 1 OF 9)
FROM RUN/START RELAY (DIAGRAM 4 OF 9)
FROM STOP/ START RELAY (DIAGRAM 7 OF 9)
FROM VACUUM CLEANER RELAY (DIAGRAM 2 OF 9)
FRONT BLOWER MOTOR RELAY
FUEL PUMP RELAY
FUSE 17
FUSE 40
FUSE 88
FUSE 89
FUSE 91
FUSE 96
HEADLAMP WASHER RELAY
HEATED SEATS MODULE
HORN RELAY
LEFT HID HEADLAMPS RELAY
LEFT SEAT BACK VENT MOTOR
LEFT SEAT CUSHION VENT MOTOR
OCCUPANT RESTRAINT CONTROLLER MODULE
PNK/VIO WIRE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
PREMIUM
REAR BLOWER MOTOR RELAY
REAR WINDOW DEFOGGER RELAY
RIGHT HID HEADLAMPS RELAY
RIGHT SEAT BACK VENT MOTOR
RIGHT SEAT CUSHION VENT MOTOR
RUN RELAY 1
RUN RELAY 2
STARTER SOLENOID RELAY
TO FUSE 100 (DIAGRAM 4 OF 9)
TO FUSE 31 (DIAGRAM 4 OF 9)
TO STOP/START RELAY (DIAGRAM 7 OF 9)
TRANSMISSION OIL PUMP RELAY
W/ HID
W/ STOP/START SYSTEM W/O STOP/START SYSTEM
Go to component -> Power distribution circuit (3 of 9) -> W/ STOP/START SYSTEM W/O STOP/START SYSTEM
Wiring diagram w/ stop/start system w/o stop/start system (2 of 2)
ADAPTIVE CRUISE CONTROL MODULE
ANTI-LOCK BRAKES MODULE
AUTOMATIC A/C
BASE
BODY CONTROL MODULE
CLUSTER
DRIVER MEMORY SEAT MODULE
DRIVER SEAT SWITCH
DRVR POWER SEAT CIRCUIT BREAKER 1
EXCEPT PHEV
FORWARD FACING CAMERA
FROM PCR CONTROL RELAY (DIAGRAM 7 OF 9)
FROM POWER DISTRIBUTION CENTER ASSEMBLY (DIAGRAM 4 OF 9)
FROM RUN/START RELAY (DIAGRAM 4 OF 9)
FUSE 14
FUSE 15
FUSE 18
FUSE 30
FUSE 37
FUSE 44
FUSE 54
FUSE 66
FUSE 67
FUSE 94
FUSE 97
HVAC MODULE
MANUAL A/C
OCCUPANT CLASSIFICATION MODULE
OCCUPANT RESTRAINT CONTROLLER MODULE
PARK ASSIST MODULE
PASS POWER SEAT CIRCUIT BREAKER 2
PASSENGER MEMORY SEAT MODULE
PASSENGER SEAT SWITCH
PNK/GRN WIRE
PNK/LT GRN WIRE
PNK/ORG WIRE
POWER INVERTER MODULE
POWERTRAIN CONTROL MODULE
PREMIUM
REAR HVAC MODULE
RED WIRE
RED/DK GRN WIRE
SECURITY GATEWAY MODULE
STARTER SOLENOID RELAY
STEERING COLUMN LOCK MODULE
TAN/RED WIRE
TO FUSE 76 (DIAGRAM 6 OF 9)
W/ MEMORY
W/ STOP/START SYSTEM
W/ STOP/START SYSTEM W/O STOP/START SYSTEM
W/O MEMORY
Go to component -> Power distribution circuit (5 of 9) -> W/ STOP/START SYSTEM W/O STOP/START SYSTEM
