Chrysler Pacifica RU (2016-2020) veh spd sig Wiring diagram
This page shows the only wiring diagram for the component.veh spd sig, which is found in the car Chrysler Pacifica RU (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram veh spd sig (1 of 1)
AHLM
BLK WIRE
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DK BLU/ORG WIRE
DK GRN WIRE
DK GRN/ORG WIRE
ELECTRIC VEH SPEAKER (-)
FUSE 100
FUSE 44
FUSED B (+)
FUSED IGN
HOT AT ALL TIMES
HOT W/ RUN RELAY 2 ENERGIZED
PEDESTRIAN ALERT
PEDESTRIAN ALERT SOUND CTRL
PEDESTRIAN ALERT SPEAKER
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWER DISTRIBUTION SYSTEM
RED WIRE
SOUND CTRL
TAN/DK GRN WIRE
VEH SPD SIG
VEHICLE PEDESTRIAN ALERT CONTROL UNIT
WHT WIRE
WHT/GRN WIRE
Go to component -> Wiring diagram engine performance 3.6l hybrid, virtual engine sound system circuit -> VEH SPD SIG
