Chrysler Pacifica RU (2016-2020) vacuum cleaner relay Wiring diagrams
This page contains all the electrical diagrams for the component. vacuum cleaner relay, in which he is found in the car Chrysler Pacifica RU (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
vacuum cleaner relay wiring diagram (1 of 3)
BATT STATUS IND
BLK WIRE
BODY CONTROL MODULE (LEFT SIDE OF DASH)
BRN WIRE
CAN C (+)
COMPUTER DATA LINES SYSTEM
FEED
FUSE 38
FUSE 44
FUSE 77
FUSED B (+)
GROUND
HOT AT ALL TIMES
HOT W/ RUN/ACC 1 RELAY ENERGIZED
IGN SWITCH OUTPUT
ORG/TAN WIRE
PNK/YEL WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWER SAVER/ VACUUM INDICATOR LAMP
RED WIRE
RELAY CTRL
SWITCH CTRL
TAN WIRE
TAN/PNK WIRE
VACUUM ASSEMBLY
VACUUM CLEANER
VACUUM CLEANER RELAY
VACUUM CLEANER RELAY CTRL
VACUUM CLEANER SWITCH CTRL
VACUUM SWITCH
VIO/YEL WIRE
YEL WIRE
Go to component -> Cabin accessories circuit -> VACUUM CLEANER RELAY
vacuum cleaner relay wiring diagram (2 of 3)
7-WAY TRAILER TOW WIRING
ACTIVE LOW TEMPERATURE PUMP
AFTERMARKET ELECTRIC BRAKE JUMPER MODULE
AUXILIARY HIGH TEMPERATURE PUMP
BASE
BATTERY CHILLER SHUT-OFF VALVE
BATTERY PACK CONTROL MODULE
BLK WIRE
BODY CONTROL MODULE
CABIN HIGH TEMPERATURE VALVE
CAMSHAFT POSITION SOLENOID 2/1
CAMSHAFT POSITION SOLENOID 2/2
ELECTRIC COOLANT HEATER
FRONT BLOWER MOTOR RELAY
FRONT WIPER MOTOR
FUEL PUMP RELAY
GRILLE SHUTTER ACTUATOR
HEADLAMP WASHER RELAY
HIGH TEMPERATURE 3-WAY VALVE RELAY
HIGH TEMPERATURE AUXILIARY PUMP RELAY
HIGH TEMPERATURE SHUT-OFF VALVE
HORN RELAY
IGNITION COIL 2
IGNITION COIL 4
IGNITION COIL 6
LEFT FRONT FOG LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT HID HEADLAMPS RELAY
LOW TEMPERATURE ACTIVE PUMP RELAY RELAY
LOW TEMPERATURE PASSIVE PUMP RELAY
ON BOARD CHARGING MODULE
POWER CONTROL RELAY
POWER DISTRIBUTION CENTER ASSEMBLY
PREMIUM
REAR BLOWER MOTOR RELAY
REAR WINDOW DEFOGGER RELAY
REAR WIPER RELAY
RIGHT FRONT FOG LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT HID HEADLAMPS RELAY
RUN RELAY 1
RUN RELAY 2
RUN/ ACCESSORY RELAY 1
RUN/ ACCESSORY RELAY 2
RUN/ START RELAY
STOP/ START RELAY
TRANSMISSION OIL PUMP RELAY
VACUUM CLEANER RELAY
VVL SOLENOID 2/1
VVL SOLENOID 2/2
WIPER HIGH/LOW RELAY
WIPER ON/OFF RELAY
Go to component -> Ground distribution circuit (2 of 7) -> VACUUM CLEANER RELAY
vacuum cleaner relay wiring diagram (3 of 3)
