Chrysler Pacifica RU (2016-2020) trailer tow backup lp rly ctrl Wiring diagram
This page shows the only wiring diagram for the component.trailer tow backup lp rly ctrl, which is found in the car Chrysler Pacifica RU (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trailer tow backup lp rly ctrl (1 of 1)
7-WAY TRAILER TOW WIRING
BLK WIRE
BODY CONTROL MODULE
CAN C (+)
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DK GRN/BLU WIRE
DK GRN/DK BLU WIRE
FUSE 74
HOT AT ALL TIMES
LEFT LIFTGATE TAIL LAMP ASSEMBLY
LH BACKUP
LH BACKUP LP DRV
LP DRV
POWER DISTRIBUTION CENTER ASSEMBLY
RH BACKUP
RH BACKUP LP DRV
RIGHT LIFTGATE TAIL LAMP ASSEMBLY
TRAILER TOW BACKUP LAMP RELAY
TRAILER TOW BACKUP LP RLY CTRL
TRANSMISSION ASSEMBLY
TRANSMISSION CONTROL MODULE
VIO/WHT WIRE
WHT WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/TAN WIRE
YEL WIRE
Go to component -> Backup lamps circuit -> TRAILER TOW BACKUP LP RLY CTRL
