Chrysler Pacifica RU (2016-2020) power saver/ vacuum indicator lamp Wiring diagrams

BATT STATUS IND BLK WIRE BODY CONTROL MODULE (LEFT SIDE OF DASH) BRN WIRE CAN C (+) COMPUTER DATA LINES SYSTEM FEED FUSE 38 FUSE 44 FUSE 77 FUSED B (+) GROUND HOT AT ALL TIMES HOT W/ RUN/ACC 1 RELAY ENERGIZED IGN SWITCH OUTPUT ORG/TAN WIRE PNK/YEL WIRE POWER DISTRIBUTION CENTER ASSEMBLY POWER SAVER/ VACUUM INDICATOR LAMP RED WIRE RELAY CTRL SWITCH CTRL TAN WIRE TAN/PNK WIRE VACUUM ASSEMBLY VACUUM CLEANER VACUUM CLEANER RELAY VACUUM CLEANER RELAY CTRL VACUUM CLEANER SWITCH CTRL VACUUM SWITCH VIO/YEL WIRE YEL WIRE

A/C COMPRESSOR CLUTCH A/C COMPRESSOR SOLENOID BASE BLK WIRE CAMSHAFT POSITION SOLENOID 1/1 CAMSHAFT POSITION SOLENOID 1/2 CHMSL LAMP ELECTRIC HEATED BACKLITE EVAP PURGE SOLENOID EVAP SYSTEM MONITOR SWITCH EXCEPT PHEV FUEL PUMP CONTROL MODULE IGNITION COIL 1 IGNITION COIL 3 IGNITION COIL 5 LEFT LICENSE LAMP LEFT LIFTGATE TAIL LAMP ASSEMBLY LEFT POWER FOLDING SEAT RECLINER SWITCH LEFT POWER SLIDING DOOR MODULE LEFT RATCHET SWITCH LEFT REAR DOOR MODULE LEFT REAR FOG LAMP LEFT REAR HEATED SEAT SWITCH LEFT REAR POWER WINDOW SWITCH LEFT REAR SEAT CUSHION HEATER LEFT REAR SIDE MARKER LAMP LEFT STOP/TURN LAMP LEFT TAIL LAMP LIFTGATE LATCH OIL PUMP SOLENOID POWER LIFTGATE HANDLE SWITCH POWER SAVER/ VACUUM INDICATOR LAMP PREMIUM REAR WIPER MOTOR RIGHT LICENSE LAMP RIGHT REAR FOG LAMP RIGHT REAR SIDE MARKER LAMP VACUUM PUMP VACUUM SWITCH VVL SOLENOID 1/1 VVL SOLENOID 1/2
