Chrysler Pacifica RU (2016-2020) passive coolant temperature pump sensor Wiring diagram
This page shows the only wiring diagram for the component.passive coolant temperature pump sensor, which is found in the car Chrysler Pacifica RU (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passive coolant temperature pump sensor (1 of 1)
5 VOLT SPLY
A/C PRESSURE SIG
A/C PRESSURE TRANSDUCER
BATTERY COOLANT LEVEL SENSOR
BLK WIRE
BLU/BRN WIRE
BLU/DK BLU WIRE
CABIN HIGH TEMPERATURE VALVE
CHARGING PORT AC LINE 1
CHARGING PORT AC LINE 2
CHARGING PORT CTRL PILOT SIG
CHARGING PORT GND
CHARGING PORT PROXIMITY SIG
COOLANT
COOLANT SENS
COOLANT TEMP
COOLANT TEMP SNS 3
COOLANT VALVE 1 CTRL
COOLANT VALVE 1 SNS
DK BLU/TAN WIRE
DK GRN/PNK WIRE
ELECTRIC COOLANT HEATER TEMPERATURE SENSOR
ELECTRIC VEHICLE CHARGING PORT
GRY/BLU WIRE
GRY/DK BLU WIRE
GRY/TAN WIRE
GRY/VIO WIRE
HEATER CORE COOLANT TEMPERATURE SENSOR
HIGH TEMP CABIN VALVE
LT BLU/DK BLU WIRE
ORG/GRY WIRE
ORG/PNK WIRE
PASSIVE COOLANT TEMPERATURE PUMP SENSOR
PNK/GRN WIRE
PNK/ORG WIRE
RED WIRE
SENS GND 1
SENS GND 2
SNS 2
SPLY
TEMP SNS 1
VIO/DK BLU WIRE
VIO/DK GRN WIRE
VIO/WHT WIRE
WHT/DK BLU WIRE
WHT/DK GRN WIRE
YEL/BLK WIRE
YEL/DK BLU WIRE
Go to component -> Wiring diagram engine performance 3.6l hybrid, hybrid system circuit (6 of 7) -> PASSIVE COOLANT TEMPERATURE PUMP SENSOR
