Chrysler Pacifica RU (2016-2020) pass mirror fold drv Wiring diagrams
This page contains all the electrical diagrams for the component. pass mirror fold drv, in which he is found in the car Chrysler Pacifica RU (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
pass mirror fold drv wiring diagram (1 of 2)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
FUSED B (+)
GRN WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
IND DRV
LAMP RTN
LIGHT DRV
LVDS CAMERA SIG
MEMORY SELECT
MEMORY SET SWITCH
NAVIGATION SYSTEM
ORG/ WIRE
ORG/GRY WIRE
ORG/WHT WIRE
PANEL LAMP DRV
PASS MIRROR APPROACH
PASS MIRROR APPROACH LIGHT DRV
PASS MIRROR BLIND SPOT
PASS MIRROR COMMON DRV
PASS MIRROR FOLD DRV
PASS MIRROR HEATER DRV
PASS MIRROR HEATER RTN
PASS MIRROR HORIZONTAL DRV
PASS MIRROR HORIZONTAL POS SIG
PASS MIRROR SENS GND
PASS MIRROR TURN SIG
PASS MIRROR TURN SIG DRV
PASS MIRROR TURN SIG LAMP RTN
PASS MIRROR UNFOLD DRV
PASS MIRROR VERTICAL DRV
PASS MIRROR VERTICAL POS SIG
PASSENGER DOOR MODULE (CENTER OF PASSENGER'S DOOR)
PASSENGER OUTSIDE REAR VIEW MIRROR
PREMIUM
RED WIRE
RED/WHT WIRE
RH BLIND SPOT
RH COAX CABLE A
RH OUTSIDE EC MIRROR RTN
RH OUTSIDE EC MIRROR SIG
SW MUX
SW RTN
VIO/BRN WIRE
VIO/GRN WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Memory mirrors circuit (2 of 2) -> PASS MIRROR FOLD DRV
pass mirror fold drv wiring diagram (2 of 2)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAN IHS (-)
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DK BLU/WHT WIRE
FUSED B (+)
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
IND DRV
LAMP RTN
LIGHT DRV
LVDS CAMERA SIG
NAVIGATION SYSTEM
ORG/ WIRE
ORG/WHT WIRE
PASS MIRROR APPROACH
PASS MIRROR APPROACH LIGHT DRV
PASS MIRROR BLIND SPOT
PASS MIRROR COMMON DRV
PASS MIRROR FOLD DRV
PASS MIRROR HEATER DRV
PASS MIRROR HEATER RTN
PASS MIRROR HORIZONTAL
PASS MIRROR HORIZONTAL DRV
PASS MIRROR HORIZONTAL POS SIG
PASS MIRROR SENS GND
PASS MIRROR TURN SIG
PASS MIRROR TURN SIG DRV
PASS MIRROR TURN SIG LAMP RTN
PASS MIRROR UNFOLD DRV
PASS MIRROR VERTICAL
PASS MIRROR VERTICAL DRV
PASS MIRROR VERTICAL POS SIG
PASSENGER DOOR MODULE (CENTER OF PASSENGER'S DOOR)
PASSENGER OUTSIDE REAR VIEW MIRROR
POS SIG
RED WIRE
RED/WHT WIRE
RH BLIND SPOT
RH COAX CABLE A
RH OUTSIDE EC MIRROR RTN
RH OUTSIDE EC MIRROR SIG
VIO/GRN WIRE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
Go to component -> Power mirrors circuit, premium (2 of 2) -> PASS MIRROR FOLD DRV
