Chrysler Pacifica RU (2016-2020) high temperature 3-way valve relay Wiring diagrams
This page contains all the electrical diagrams for the component. high temperature 3-way valve relay, in which he is found in the car Chrysler Pacifica RU (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram high temperature 3-way valve relay (1 of 3)
7-WAY TRAILER TOW WIRING
ACTIVE LOW TEMPERATURE PUMP
AFTERMARKET ELECTRIC BRAKE JUMPER MODULE
AUXILIARY HIGH TEMPERATURE PUMP
BASE
BATTERY CHILLER SHUT-OFF VALVE
BATTERY PACK CONTROL MODULE
BLK WIRE
BODY CONTROL MODULE
CABIN HIGH TEMPERATURE VALVE
CAMSHAFT POSITION SOLENOID 2/1
CAMSHAFT POSITION SOLENOID 2/2
ELECTRIC COOLANT HEATER
FRONT BLOWER MOTOR RELAY
FRONT WIPER MOTOR
FUEL PUMP RELAY
GRILLE SHUTTER ACTUATOR
HEADLAMP WASHER RELAY
HIGH TEMPERATURE 3-WAY VALVE RELAY
HIGH TEMPERATURE AUXILIARY PUMP RELAY
HIGH TEMPERATURE SHUT-OFF VALVE
HORN RELAY
IGNITION COIL 2
IGNITION COIL 4
IGNITION COIL 6
LEFT FRONT FOG LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT HID HEADLAMPS RELAY
LOW TEMPERATURE ACTIVE PUMP RELAY RELAY
LOW TEMPERATURE PASSIVE PUMP RELAY
ON BOARD CHARGING MODULE
POWER CONTROL RELAY
POWER DISTRIBUTION CENTER ASSEMBLY
PREMIUM
REAR BLOWER MOTOR RELAY
REAR WINDOW DEFOGGER RELAY
REAR WIPER RELAY
RIGHT FRONT FOG LAMP
RIGHT FRONT SIDE MARKER LAMP
RIGHT HID HEADLAMPS RELAY
RUN RELAY 1
RUN RELAY 2
RUN/ ACCESSORY RELAY 1
RUN/ ACCESSORY RELAY 2
RUN/ START RELAY
STOP/ START RELAY
TRANSMISSION OIL PUMP RELAY
VACUUM CLEANER RELAY
VVL SOLENOID 2/1
VVL SOLENOID 2/2
WIPER HIGH/LOW RELAY
WIPER ON/OFF RELAY
Go to component -> Ground distribution circuit (2 of 7) -> HIGH TEMPERATURE 3-WAY VALVE RELAY
Wiring diagram high temperature 3-way valve relay (2 of 3)
A/C CLUTCH RELAY
AHLM
ANTI-LOCK BRAKES MODULE
AUTOMATIC A/C
BASE
BODY CONTROL MODULE
BRN WIRE
ELECTRIC BRAKE BOOSTER MODULE
EPS MODULE
EXCEPT AHLM
EXCEPT PHEV
FROM RUN RELAY 1 (DIAGRAM 3 OF 9)
FROM RUN RELAY 2 (DIAGRAM 3 OF 9)
FUSE 10
FUSE 100
FUSE 31
FUSE 52
FUSE 56
FUSE 6
HEADLAMP LEVELING MODULE
HEADLAMP SWITCH
HIGH TEMPERATURE 3-WAY VALVE RELAY
HIGH TEMPERATURE AUXILIARY PUMP RELAY
LOW TEMPERATURE ACTIVE PUMP RELAY
LOW TEMPERATURE PASSIVE PUMP RELAY
MANUAL A/C
PHEV AHLM
PNK WIRE
PNK/GRN WIRE
PNK/YEL WIRE
PREMIUM
RUN/ START RELAY
TO FUSE 54 (DIAGRAM 5 OF 9)
TO FUSE 67 (DIAGRAM 5 OF 9)
TO REAR VIDEO CAMERA (DIAGRAM 2 OF 9)
TO RUN RELAY 1 (DIAGRAM 3 OF 9)
VACUUM PUMP RELAY
VEHICLE PEDESTRIAN ALERT CONTROL UNIT
W/ BLIND SPOT
W/O BLIND SPOT
YEL WIRE
Go to component -> Power distribution circuit (4 of 9) -> HIGH TEMPERATURE 3-WAY VALVE RELAY
Wiring diagram high temperature 3-way valve relay (3 of 3)
A/C COMPRESSOR
BATT CHILLER VALVE CTRL
BATTERY ACCESS COVER HVIL
BLK WIRE
BRN/TAN WIRE
BRN/VIO WIRE
CAN C (+)
CAN C (-) EPT
COMPUTER DATA
COMPUTER DATA LINES SYSTEM
COOLANT VALVE 1 CTRL
COOLANT VALVE 2 CTRL
COOLING FANS SYSTEM
DK GRN/GRY WIRE
DK GRN/PNK WIRE
ELECTRIC A/C COMPRESSOR FUSE
FUSE 10
FUSE 20
FUSE 30
FUSE 31
FUSE 6
FUSED IGN SW O/P (RUN START)
GRY/ORG WIRE
HIGH TEMPERATURE 3-WAY VALVE RELAY
HIGH TEMPERATURE AUXILIARY PUMP RELAY
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
LINES SYSTEM
LOW TEMPERATURE ACTIVE PUMP RELAY
LOW TEMPERATURE PASSIVE PUMP RELAY
MASTER WAKE-UP SIG
MOTOR ACCESS COVER HVIL
N/A
ORG/ WIRE
ORG/BLK WIRE
ORG/GRY WIRE
ORG/WHT WIRE
PIM LIN BUS 1 (A)
PNK/GRN WIRE
PNK/ORG WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
POWER INVERTER MODULE
RADIATOR FAN CTRL SIG
SHUT-OFF VALVE CTRL
THERMAL SYS RELAY 1 CTRL
TRANSMISSION OIL PUMP RELAY
TRS PARK SIG
VIO/ORG WIRE
VIO/YEL WIRE
WHT/BLU WIRE
WHT/DK BLU WIRE
WHT/ORG WIRE
YEL WIRE
YEL/BLK WIRE
YEL/DK BLU WIRE
YEL/VIO WIRE
Go to component -> Wiring diagram engine performance 3.6l hybrid, hybrid system circuit (4 of 7) -> HIGH TEMPERATURE 3-WAY VALVE RELAY
