Chrysler Pacifica RU (2016-2020) detection return Wiring diagrams
This page contains all the electrical diagrams for the component. detection return, in which he is found in the car Chrysler Pacifica RU (2016-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram detection return (1 of 2)
ANCHOR
BLU/BLK WIRE
BLU/DK GRN WIRE
BLU/GRY WIRE
BLU/VIO WIRE
BRN/GRN WIRE
BUCKLE SW SENS
DETECTION RETURN
DK BLU/ORG WIRE
DK BLU/VIO WIRE
DK GRN/BLU WIRE
DK GRN/DK BLU WIRE
DK GRN/ORG WIRE
DRIVER SEAT BELT ANCHOR PRETENSIONER
DRIVER SEAT BELT BUCKLE TENSIONER SWITCH
DRIVER SEAT TRACK POSITION SENSOR
DRV SEAT
DRV SEAT BELT
GRN/BLK WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/TAN WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/WHT WIRE
LEFT SEAT THORAX
LEFT SIDE IMPACT
LEFT SIDE IMPACT B PILLAR SENSOR
LEFT SIDE IMPACT D PILLAR SENSOR
LEFT SIDE THORAX AIR BAG
LIMITER LINE 1
LIMITER LINE 2
ORG/TAN WIRE
ORG/VIO WIRE
PASS LOAD
PASS SEAT BELT
PASSENGER SEAT BELT ANCHOR PRETENSIONER
PASSENGER SEAT BELT RETRACTOR TENSIONER
PNK/ORG WIRE
PNK/VIO WIRE
POS SENS VOLT
RETRACTOR
RIGHT CURTAIN
RIGHT SEAT THORAX
RIGHT SIDE CURTAIN AIR BAG
RIGHT SIDE THORAX AIR BAG
SENS 1 GND
SENS 1 SIG
SQUIB 1 LINE 1
SQUIB 1 LINE 2
TAN/BLU WIRE
TAN/GRN WIRE
TENSIONER LINE 1
TENSIONER LINE 2
VIO/BLU WIRE
W/O POWER SEATS W/ POWER SEATS
Go to component -> Supplemental restraints circuit (2 of 4) -> DETECTION RETURN
Wiring diagram detection return (2 of 2)
BLK WIRE
BLU/BLK WIRE
BLU/DK GRN WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN/GRN WIRE
CAN C (+)
COMPUTER DATA LINES SYSTEM
DETECTION RETURN
DETECTION SIG
DK BLU/BLU WIRE
DK BLU/WHT WIRE
DK GRN/ORG WIRE
DRIV KNEE BLOCKER
DRIV SQUIB 2
DRIV SQUIB 3
DRIVER AIR BAG SQUIB 2
DRIVER AIR BAG SQUIB 3
DRIVER KNEE BLOCKER AIR BAG
FUSE 56
GRN WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY/ORG WIRE
GRY/WHT WIRE
HOT W/ RUN/START RELAY ENERGIZED
LEFT SIDE CURTAIN AIR BAG
LH CURTAIN (-)
LINE 1-
LINE 2-
OCCUPANT CLASSIFICATION MODULE
OCCUPANT DETECTION SENSOR
ORG/DK BLU WIRE
PASS KNEE BLOCKER
PASS SEAT
PASS SEAT BELT
PASS SEAT OCCUPANT
PASS SEAT POS
PASSENGER KNEE BLOCKER AIR BAG
PASSENGER SEAT BELT BUCKLE TENSIONER SWITCH
PASSENGER SEAT TRACK POSITION SENSOR
PNK WIRE
PNK/GRN WIRE
PNK/ORG WIRE
PNK/VIO WIRE
POWER DISTRIBUTION CENTER ASSEMBLY
RIGHT SIDE IMPACT
RIGHT SIDE IMPACT B PILLAR SENSOR
RIGHT SIDE IMPACT D PILLAR SENSOR
RUN/START RELAY
SENS 1 GND
SENS 1 SIG
SENS VOL -
SQUIB 1 LINE 1
SQUIB 1 LINE 2
SQUIB LINE 1
SQUIB LINE 2
STEERING WHEEL)
SW SENS
TAN/GRN WIRE
VIO/BLU WIRE
W/O REAR HVAC W/ REAR HVAC
YEL WIRE
YEL/BLU WIRE
Go to component -> Supplemental restraints circuit (3 of 4) -> DETECTION RETURN
