Chrysler Pacifica RU (2016-2020) d-pillar power folding seat switch Wiring diagram
This page shows the only wiring diagram for the component.d-pillar power folding seat switch, which is found in the car Chrysler Pacifica RU (2016-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram d-pillar power folding seat switch (1 of 1)
BLK WIRE
D-PILLAR POWER FOLDING SEAT SWITCH
FOLDING SEAT
FOLDING SEAT HEADREST MTR RTN
FOLDING SEAT LATCH RTN
FOLDING SEAT NORMAL/
FOLDING SEAT RECLINER
FOLDING SEAT SELECT
GRN/BLK WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/DK BLU WIRE
GRN/GRY WIRE
GRN/ORG WIRE
GRN/TAN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HEADREST MTR
HEADREST MTR RTN
IGN SW OUTPUT
LATCH RTN
LATCH SW SIG
LEFT POWER REAR FOLDING SEAT LATCH
LH FOLDING SEAT
PNK/YEL WIRE
POS HALL SENS SIG
POWER DISTRIBUTION SYSTEM
RECLINER FWD DRV
RECLINER RWD DRV
RH FOLDING
RH FOLDING SEAT
RH FOLDING SEAT HEADREST MTR RWD DRV
RH FOLDING SEAT UNLATCH DRV
RIGHT POWER FOLDING SEAT RECLINER SWITCH
RIGHT POWER REAR FOLDING SEAT LATCH
RWD DRV
SEAT RECLINER
SEAT STOW
SENS/SW RTN
STOW MTR FWD DRV
STOW MTR RWD DRV
STOW SW MUX SIG
SW MUX SIG
TAN WIRE
TAN/DK BLU WIRE
TAN/GRY WIRE
UNLATCH DRV
Go to component -> Third row folding seat circuit (2 of 2) -> D-PILLAR POWER FOLDING SEAT SWITCH
