Chrysler Pacifica CS (2003-2008) pass heated mirror feed Wiring diagram
This page shows the only wiring diagram for the component.pass heated mirror feed, which is found in the car Chrysler Pacifica CS (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass heated mirror feed (1 of 1)
BLK/BRN WIRE
BLK/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER RELAY CONTROL
DK BLU WIRE
DK BLU/GRY WIRE
DRIVER DOOR MODULE
DRIVER HEAT MIR DRV
DRIVER HEAT MIR FEED
DRIVER HEATED MIRROR DRIVER
DRIVER HEATED MIRROR FEED
DRIVER POWER MIRROR
FUSE 5
GROUND
HOT AT ALL TIMES
INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT)
INTEGRATED POWER MODULE REAR WINDOW
LT BLU/WHT WIRE
LT GRN/ORG WIRE
ORG/LT GRN WIRE
PASS HEAT MIR DRV
PASS HEAT MIR FEED
PASS HEATED MIRROR DRIVER
PASS HEATED MIRROR FEED
PASSENGER DOOR MODULE
PASSENGER POWER MIRROR
PCI BUS
REAR DEFOGGER WINDOW
REAR WINDOW DEFOGGER RELAY
WHT WIRE
WHT/VIO WIRE
Go to component -> Defoggers circuit -> PASS HEATED MIRROR FEED
