Chrysler Pacifica CS (2003-2008) output speed sensor sns sig wiring diagram
This page shows the only wiring diagram for the component.output speed sensor sns sig, which is found in the car Chrysler Pacifica CS (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
output speed sensor sns sig wiring diagram (1 of 1)
3.8L
BLK/LT GRN WIRE
BLK/VIO WIRE
BRAKE LAMP SWITCH (LEFT SIDE OF DASH)
BRN/ORG WIRE
CLOCKSPRING (AT TOP OF STEERING COLUMN)
COAST
COMPUTER DATA LINES SYSTEM
DIAGNOSTIC
DK BLU WIRE
DK BLU/DK GRN WIRE
DK GRN WIRE
DK GRN/BRN WIRE
DK GRN/ORG WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DUMP
ENGINE CONTROLS SYSTEM
FUSE 39
FUSED B (+)
GROUND
HOT AT ALL TIMES
INPUT SPEED SENS SIG
INPUT SPEED SENSOR GROUND
INSTRUMENT CLUSTER
INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPARTMENT)
LEFT SPEED CONTROL SWITCH
ORG/RED WIRE
OUTPUT SPEED SENS SIG
OUTPUT SPEED SENSOR SNS SIG
PCI BUS
PCI BUS (CRUISE INDICATOR)
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
RESUME/ ACCEL
RIGHT SPEED CONTROL SWITCH
S/C SUPPLY
S/C SW SIG
SENS GND
SENSOR GND
SET-
SNS SIG
SPEED CONTROL SERVO (LEFT FRONT OF ENGINE COMPT) VENT
SPEED SENS GND TRANSMISSION TEMP SENS SIG
THROTTLE POSITION SENSOR (REAR OF ENGINE)
TP SIG
TRANSMISSION RANGE SENSOR (LEFT SIDE OF TRANSMISSION)
TRANSMISSION TEMP SENS SIG
VACUUM
VACUUM CTRL
VENT CTRL
VIO WIRE
VIO/ORG WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/VIO WIRE
YEL/VIO WIRE
Go to component -> Cruise control circuit -> OUTPUT SPEED SENSOR SNS SIG
