Chrysler Pacifica CS (2003-2008) mirrors system wiring diagram
This page shows the only wiring diagram for the component.mirrors system, which is found in the car Chrysler Pacifica CS (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
mirrors system wiring diagram (1 of 1)
ACCESSORY RELAY
AUTOMATIC HEADLAMP SIGNAL
B(+) RELAY FUSE 3
BACK-UP LAMP SIGNAL
BLK/DK BLU WIRE
BLK/GRY WIRE
BLK/PNK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LEFT KICK PANEL)
CLOSE
COMPUTER DATA LINES SYSTEM
DOME LAMPS DIMMER SIG
ELECTRONICS
FRONT READING LAMP
FUSE 25
FUSE 48
GRY/RED WIRE
HOMELINK BUTTON BAR
HOT AT ALL TIMES
INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT)
LIFTGATE SW MUX
LIFTGATE SWITCH MUX
LT BLU WIRE
MIRRORS SYSTEM
ORG/ WIRE
ORG/LT BLU WIRE
ORG/TAN WIRE
ORG/WHT WIRE
ORG/YEL WIRE
OVERHEAD CONSOLE
PCI BUS
PNK/ORG WIRE
POWER SUNROOF MODULE (W/ POWER SUNROOF) (REAR OF SUNROOF)
POWER SUNROOF SWITCH
RELAY
RUN WIRE
SUNROOF VENT SUNROOF CLOSE SUNROOF OPEN
TAN WIRE
VENT
VIO WIRE
VIO/TAN WIRE
WHT WIRE
WHT/VIO WIRE
YEL WIRE
Go to component -> Overhead console circuit -> MIRRORS SYSTEM
