Chrysler Pacifica CS (2003-2008) low/ reverse pressure switch Wiring diagram
This page shows the only wiring diagram for the component.low/ reverse pressure switch, which is found in the car Chrysler Pacifica CS (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low/ reverse pressure switch (1 of 1)
2-4 PRESSURE SWITCH
2-4 SOLENOID
AUTO SHUT DOWN RELAY
BLK/LT GRN WIRE
BLK/ORG WIRE
BRN WIRE
BRN/GRY WIRE
BRN/ORG WIRE
BRN/WHT WIRE
DK BLU/ORG WIRE
DK BLU/YEL WIRE
DK GRN/TAN WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
FUEL PUMP RELAY
FUSE 36
FUSE 37
FUSE 38
HOT AT ALL TIMES
HOT IN RUN OR START
INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT)
LOW/ REVERSE PRESSURE SWITCH
LOW/ REVERSE SOLENOID
LT BLU/BRN WIRE
ORG/RED WIRE
OVERDRIVE PRESSURE SWITCH
OVERDRIVE SOLENOID
TRANS- MISSION CONTROL RELAY
TRANSMISSION SOLENOID/PRESSURE SWITCH ASSEMBLY (LEFT SIDE OF TRANSMISSION)
UNDERDRIVE SOLENOID
VIO/LT BLU WIRE
VIO/WHT WIRE
WHT/DK GRN WIRE
YEL/BRN WIRE
YEL/DK GRN WIRE
YEL/GRY WIRE
YEL/LT BLU WIRE
YEL/ORG WIRE
YEL/TAN WIRE
Go to component -> Wiring diagram engine performance 3.5l (4 of 5) -> LOW/ REVERSE PRESSURE SWITCH
