Chrysler Pacifica CS (2003-2008) drv htd mirror drv Wiring diagram
This page shows the only wiring diagram for the component.drv htd mirror drv, which is found in the car Chrysler Pacifica CS (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram drv htd mirror drv (1 of 1)
AUTO DAY/NIGHT MIRROR (-)
AUTOMATIC DAY/NIGHT MIRROR CIRCUIT
B(+)
BLK/BRN WIRE
DK BLU/GRY WIRE
DOOR NODE
DOOR NODE RELAY
DRIVER DOOR MODULE
DRIVER POWER MIRROR
DRV HTD MIRROR DRV
DRV HTD MIRROR FEED
DRV MIRROR COMMON DRV
DRV MIRROR HORIZ DRV
DRV MIRROR HORIZ POS SIG
DRV MIRROR SENS GND
DRV MIRROR SENS SPLY
DRV MIRROR SNS SPLY
DRV MIRROR VERT DRV
DRV MIRROR VERT POS SIG
FUSE 3
FUSE 40
FUSE 41
FUSE 46
FUSE 47
FUSED B (+)
FUSED DOOR NODE RELAY OUT
FUSED NODE RELAY OUT
GROUND
HOT AT ALL TIMES
INTEGRATED POWER MODULE
INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT)
LT BLU WIRE
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/ORG WIRE
ORG/LT GRN WIRE
ORG/TAN WIRE
PASS HTD MIRROR DRV
PASS HTD MIRROR FEED
PASS HTD MIRROR PASS
PASS MIRROR COMMON DRV
PASS MIRROR COMMON PASS
PASS MIRROR HORIZ DRV
PASS MIRROR HORIZ PASS
PASS MIRROR HORIZ POS SIG
PASS MIRROR HORZ POS SIG
PASS MIRROR SENS GND
PASS MIRROR SENS SPLY
PASS MIRROR VERT DRV
PASS MIRROR VERT PASS
PASS MIRROR VERT POS SIG
PASSENGER DOOR MODULE PASSENGER DOOR MODULE
PASSENGER POWER MIRROR
PNK WIRE
PNK/LT BLU WIRE
RED WIRE
RED/LT BLU WIRE
RED/LT GRN WIRE
RELAY
RELAY CTRL
RUN WIRE
TAN WIRE
TAN/DK GRN WIRE
TAN/GRY WIRE
TAN/LT BLU WIRE
TAN/LT GRN WIRE
TAN/ORG WIRE
TAN/VIO WIRE
TAN/WHT WIRE
TAN/YEL WIRE
VIO/TAN WIRE
WHT/TAN WIRE
Go to component -> Memory mirrors circuit -> DRV HTD MIRROR DRV
