Chrysler Pacifica CS (2003-2008) auto stick upshift sw sig Wiring diagram
This page shows the only wiring diagram for the component.auto stick upshift sw sig, which is found in the car Chrysler Pacifica CS (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto stick upshift sw sig (1 of 1)
AUTO STICK DNSHIFT SW SIG
AUTO STICK DOWNSHIFT SW SIG
AUTO STICK UPSHIFT SW SIG
BLK/LT GRN WIRE
BLK/ORG WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BRAKE LAMP SW OUT
BRAKE LAMP SWITCH (LEFT SIDE OF DASH)
BRAKE SW SIG
DK GRN WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
FRONT CONTROL MODULE
FUSE 29
FUSED B (+)
GROUND
HOT AT ALL TIMES
IGN SW OUT (RUN-START)
INSTRUMENT CLUSTER
INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT)
LT GRN WIRE
LT GRN/RED WIRE
ORG/GRY WIRE
PNK WIRE
PNK/YEL WIRE
PNL LAMPS DRV
POWERTRAIN CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
RED WIRE
SHIFT LEVER ASSEMBLY
WHT WIRE
WHT/DK GRN WIRE
YEL WIRE
YEL/DK GRN WIRE
Go to component -> Shift interlock circuit -> AUTO STICK UPSHIFT SW SIG
