Chrysler Pacifica CS (2003-2008) auto headlamp sig Wiring diagram
This page shows the only wiring diagram for the component.auto headlamp sig, which is found in the car Chrysler Pacifica CS (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram auto headlamp sig (1 of 1)
10 9 AUTO DAY/NIGHT MIRR(+) AUTO DAY/NIGHT MIRR(-)
12 11 BACK-UP LAMP SIG AUTO HEADLAMP SIG
ACCESSORY RELAY
AUTO HEADLAMP SIG
AUTOMATIC DAY/NIGHT MIRROR
BLK/DK BLU WIRE
BLK/GRY WIRE
BLK/LT BLU WIRE
BLK/ORG WIRE
BLK/PNK WIRE
BLK/WHT WIRE
DRIVER POWER MIRROR
HOT AT ALL TIMES
INTEGRATED POWER MODULE (LEFT FRONT FUSE 25 OF ENGINE COMPT)
OVERHEAD CONSOLE
TAN/ORG WIRE
TAN/WHT WIRE
Go to component -> Automatic day/night mirror circuit -> AUTO HEADLAMP SIG
