Chrysler Pacifica CS (2003-2008) ajar sw sense Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 OPTICAL SENS SUPPLY 1 2 3 4 5 6 7 8 LATCH CLUTCH DRIVER LIFTGATE OPEN DRIVER LIFTGATE CLOSE DRIVER AJAR SW SENSE BLK/GRY WIRE BLK/ORG WIRE BODY CONTROL MODULE (LEFT KICK PANEL) COMPUTER DATA LINES SYSTEM DK GRN BLK/ WIRE FUSE 11 FUSED B (+) GROUND GRY BLK/ WIRE HANDLE SW SNS HOT AT ALL TIMES INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT) LICENSE LAMP GROUND SENSOR SIGNAL LIFTGATE CINCH/ RELEASE MOTOR (LOWER CENTER OF POWER LIFTGATE) LIFTGATE CLUTCH DRIVER LATCH CINCH DRIVER LATCH RELEASE DRIVER LIFTGATE HANDLE SWITCH (CENTER OF LIFTGATE) LIFTGATE LEFT PINCH SENSOR (LEFT SIDE OF POWER LIFTGATE) LIFTGATE RIGHT PINCH SENSOR (RIGHT SIDE OF POWER LIFTGATE) OPTICAL SENSE ORG/ WIRE ORG/DK BLU WIRE ORG/DK GRN WIRE ORG/GRY WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE ORG/TAN WIRE ORG/VIO WIRE ORG/YEL WIRE PCI BUS PINCH SENSOR SIGNAL POWER POWER LIFTGATE DRIVE UNIT (LEFT REAR CORNER OF VEHICLE) POWER LIFTGATE MODULE (LEFT REAR CORNER OF VEHICLE) RED WIRE SIGNAL 1 SIGNAL 2 TAN/BRN WIRE TAN/DK GRN WIRE TAN/GRY WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/WHT WIRE TEMP VEHICLE VIO/GRY WIRE VIO/LT BLU WIRE VIO/ORG WIRE WAKE UP SIGNAL WHT/VIO WIRE YEL WIRE YEL/RED WIRE
