Chrysler Pacifica CS (2003-2008) 3 1 2 sens gnd sens supply sens 8 sig Wiring diagram
This page shows the only wiring diagram for the component.3 1 2 sens gnd sens supply sens 8 sig, which is found in the car Chrysler Pacifica CS (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 3 1 2 sens gnd sens supply sens 8 sig (1 of 1)
1 2 3 SENS SUPPLY SENS 7 SIG SENS GND
1 2 3 SENS SUPPLY SENS 9 SIG SENS GND
1 3 2 DISPLAY SUPPLY DISPLAY SIG DISPLAY GND
2 1 3 SENS 10 SIG SENS SUPPLY SENS GND
3 1 2 SENS GND SENS SUPPLY SENS 8 SIG
BLK WIRE
DK GRN WIRE
DK GRN/BLK WIRE
DK GRN/GRY WIRE
GRY/BLK WIRE
GRY/LT BLU WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
IGN SW OUTPUT (RUN-START) GROUND PCI BUS
IGNITION SWITCH
INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPARTMENT)
LOCK OFF
PARK ASSIST DISPLAY MODULE (PARKTRONICS) (NEAR TOP CENTER OF LIFTGATE)
PARK ASSIST MODULE (PARKTRONICS) (LEFT REAR OF VEHICLE)
PARK ASSIST SENSOR 10 (ON REAR FASCIA)
PARK ASSIST SENSOR 7 (ON REAR FASCIA)
PARK ASSIST SENSOR 7 SIG PARK ASSIST SENSOR 8 SIG PARK ASSIST SENSOR GROUND
PARK ASSIST SENSOR 8 (ON REAR FASCIA)
PCI BUS
PNK/GRY WIRE
RUN WIRE
VIO WIRE
WHT WIRE
WHT/DK BLU WIRE
WHT/GRY WIRE
WHT/LT BLU WIRE
WHT/ORG WIRE
WHT/VIO WIRE
Go to component -> Parking assistant circuit -> 3 1 2 SENS GND SENS SUPPLY SENS 8 SIG
