Chrysler Pacifica CS (2003-2008) 26 27 autostick dn autostick up wiring diagram
This page shows the only wiring diagram for the component.26 27 autostick dn autostick up, which is found in the car Chrysler Pacifica CS (2003-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
26 27 autostick dn autostick up wiring diagram (1 of 1)
12 9 7 15 DATA LINK CONNECTOR (UNDER LEFT SIDE OF DASH)
20 21 27 29 ECT SIG TP SIG SENSOR GND
26 27 AUTOSTICK DN AUTOSTICK UP
BLK WIRE
BLK/BRN WIRE
BLK/DK GRN WIRE
BLK/LT GRN WIRE
BLK/ORG WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BRN/ORG WIRE
BRN/WHT WIRE
DK BLU/DK GRN WIRE
DK BLU/YEL WIRE
DK GRN/BRN WIRE
DK GRN/DK BLU WIRE
DK GRN/ORG WIRE
DK GRN/TAN WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
DOWNSHIFT
ENGINE CONTROLS SYSTEM
FUSE 36
HOT AT ALL TIMES
IGN SW
IGNITION SWITCH
INPUT SPEED SENSOR (LEFT SIDE OF TRANSMISSION)
INTEGRATED POWER MODULE
INTEGRATED POWER MODULE (LEFT FRONT OF ENGINE COMPT)
LAMP DRV
LOCK OFF
LOW/ REV SOL 2-4 SOL UNDER DRIVE SOL OVER DRIVE SOL OVERDRIVE PRESSURE SWITCH
LOW/ REVERSE PRESSURE SWITCH 2-4 PRESSURE SWITCH
LT BLU/DK GRN WIRE
NOL
ORG/GRY WIRE
OUTPUT SPEED SENSOR (LEFT SIDE OF TRANSMISSION)
PNK/GRY WIRE
PNK/WHT WIRE
PNK/YEL WIRE
POWERTRAIN CONTROL MODULE (PCM) (LEFT FRONT OF ENGINE COMPT)
PRNL
RUN WIRE
SHIFT LEVER ASSEMBLY
SIGNAL
START RUN
TNS RLY CTRL O/D SW SENS
TNS RLY OUT
TNS RLY OUT L/R SW SNS 2-4 SW SNS OSS SENS SIG IN SPD SIG VSS GND TNS TEMP SIG
TRANS TEMP SENSOR
TRANSMISSION CONTROL RELAY
TRANSMISSION RANGE SENSOR (LEFT SIDE OF TRANSMISSION)
TRANSMISSION SOLENOID/ PRESSURE SWITCH ASSEMBLY (LEFT SIDE OF TRANSMISSION)
UNLK
UPSHIFT
VIO/ORG WIRE
WHT/BRN WIRE
WHT/DK GRN WIRE
WHT/GRY WIRE
WHT/LT GRN WIRE
YEL/BRN WIRE
YEL/DK BLU WIRE
YEL/DK GRN WIRE
YEL/GRY WIRE
YEL/LT BLU WIRE
YEL/ORG WIRE
YEL/TAN WIRE
Go to component -> Transmission circuit -> 26 27 AUTOSTICK DN AUTOSTICK UP
